Home > Electrical & Electronics > Connector & Terminals > Terminal Blocks > Distribution Terminal Blocks KE Series for Al/Cu Connetor
Distribution Terminal Blocks KE Series for Al/Cu Connetor
US$ 0.03 - 0.1
MOQ: 10000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
UTL
Model Number:
JUT10-50
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hydraulic Cable Crimping Tool EP-430 16mm -150mmUS$ 0.15 - 0.75MOQ: 1 -
0-18 Contacts 1000v Phoenix Din Rail Terminal BlockUS$ 0.01 - 0.1MOQ: 1000 Pieces
-
Multi-conductor Spring Cage Terminal Connector 3 Conductor 6mm UL RoHSUS$ 0.001 - 0.15MOQ: 1
-
Din Rail Mounted Electric Terminal Block, Spring Type TerminalsUS$ 1.5 - 5MOQ: 10000 Pieces
-
Screw Terminal Blocks Connector SAK16EN 16mm 10mm UL 2015US$ 0.001 - 0.15MOQ: 1
Place of Origin
Zhejiang, China
Brand Name
UTL
Model Number
JUT10-50
Conductor Size
1- 5 AWG
Type
Other, Screw, JUT10 series universal large current terminals
Products Details
JUT10 series universal large current terminals
Conductor Cross-section(mm²): Cu 2.5~50mm² Al 6~50mm²
Coneductor Size(AWG): 1/0~6
Cover Material: Polyamide
Mounting: DIN rail
Screw: Hexagon 5mm
Operating Temperature(°C): Max 80°C
Standard: EN61238-1,EN60947-7-2
Parameter Sheet
More items supplied of JUT10 series universal temrinals!
| Model No. | Color | Pole | Tighten torque(Nm) | Current(A) | Voltage(V) | Weight(g) |
| JUT10-50-PE | Yellow/Green | 1 pole | 4Nm(35~95mm²) | Cu:160A | 800V | 35g |
| JUT10-50-GY | Grey | Al/Cu | 12Nm(120~150mm²) | Al: 145A | ||
| JUT10-50-BE | Blue | 2.5~50mm² | ||||
| JUT10-95-PE | Yellow/Green | 1 pole | 20Nm | Cu: 245A | 800V | 90g |
| JUT10-95-GY | Grey | Al/Cu | Al: 220A | |||
| JUT10-95-BE | Blue | 16~95mm² | ||||
| JUT10-150-PE | Yellow/Green | 1 pole | 14Nm(35~95mm²) | Cu: 320A | 750V | 160g |
| JUT10-150-GY | Grey | Al/Cu | 24Nm(120~150mm²) | Al: 290A | ||
| JUT10-150-BE | Blue | 35~150mm² | ||||
| JUT10-240-PE | Yellow/Green | 1 pole | 12Nm(35~70mm²) | Cu: 425A | 800V | 306g |
| JUT10-240-GY | Grey | Al/Cu | 40Nm(95~240mm²) | Al: 380A | ||
| JUT10-240-BE | Blue | 35~240mm² |
