Help CenterAD16-22D/S23 AC/DC 24 Volt Green Light LED Indicator Signal Lamp Bulbs 20mA
Related Products
-
Double-color Indicator Light for Isolation Brake Position IP65 24V to 380VUS$ 2 - 3MOQ: 500 Pieces -
Hot Sale Manufacturer Led Indicator Light Flash BuzzerUS$ 0.001 - 10MOQ: 100 Pieces
-
AC/DC 24V LED Power Indicator Pilot Signal Lamp 22mm Red LightUS$ 0.000001 - 1MOQ: 1000 Pieces
-
AD108-22DS Emergency D Type Led Indicator LightUS$ 0.001 - 10MOQ: 100 Pieces
-
LED Indicator Light for Earthing ConnectingUS$ 1 - 1.5MOQ: 1 Piece
1. The ultra-short type is suitable for installing in a narrow space.
2. All lights are suitable for mounting holesΦ22~ Φ25 without additional accessories.
3. All the signal lamp should adopt high-luminace LED light source.
4. DC power supply can be replaced by AC.
5. For heat dissipation condition, the electric discharge lamp and over DC220V has no super-short type, so we could provide common signal lamp abd common discharge lamp.
| Voltage(max) | 660V |
| Ui Rated Insylation Voltage | AC660V 50HZ |
| Ith Conventional Current | 10A |
| Contact Resistance | ≤50mΩ |
| Protective | IP65 |
| Insulation Material | PA66 |
| Operdtion Category | AC-15 DC-13 |
| Installation Height | 2000M |
| Polution Class | 3 |
| Operation Temperature | -25°c~+55°c |
| Viberation Durability | 10~200HZ 1mm.10g |
Package : standard package
Leading time : small or sample within 7 days large quantity 10-15 days
WHO WE ARE ?
UTILITY ELECTRICAL CO.,LTD is a well established manufacturer of Terminal Block with 25 years experience . Our company's efforts of striving to provide world-class products and services have resulted in establishing of a solid foundation to spread our wings and expand our horizons into the global market. In addition to providing quality products, we are keen to tailor our services and solutions to suite your business needs. We have also expanded our regional sales to a national level to provide our clients with a one to one service, wherever they may be located. As an independent company, we still are obliged only to answer to you –OUR CUSTOMER
When you chose our products ,but not sure which one is exactly you need ,please tell me the following question I will find out the perfect one for you !
1 Application ?
2 Which type you need(Din-Rail , PCB or Other )
3 the parameter of the terminal you need ( Thickness , AWG ,Current Voltage more detail is welcome )
4 If you can not find the one you looking for in our company you can let me know or attach the sample to us we have our own R&D Center we will give you better solution
YOU can reach me :
Skype: Sam-UTL
Mobile: +86 13703908207
Your satisfaction is my infinite power!
