Hot Sale Customizable Pultrusion Machine for Fiberglass Duct Rodder
US$ 100000.00 - 100000.00
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
HBGMEC
Model Number:
HBG2002
Payment & Shipping
Payment Methods:
Port of Shipment:
XINGANG QINGDAO SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sale Customizable Profile Pultrusion LineUS$ 100000.00 - 100000.00MOQ: 1 Set -
Hot Sale Customizable Manufacturer Pultrusion EquipmentUS$ 100000.00 - 100000.00MOQ: 1 Set
-
Hot Sale Customizable L SHAPE Pultrusion LineUS$ 100000.00 - 100000.00MOQ: 1 Set
-
Hot Sale Customizable Hydraulic Frp Pultrusion MachineUS$ 100000.00 - 100000.00MOQ: 1 Set
-
Hot Sale Customizable High Strength Fiberglass Pultrusion EquipmentUS$ 100000.00 - 100000.00MOQ: 1 Set
Place of Origin
China
Brand Name
HBGMEC
Model Number
HBG2002
After-sales Service Provided
Engineers available to service machinery overseas
Hydraulic Pultrusion Machine for box shape profile
Feature of pultrusion Equipment:
- Maximum Pulling force (Pressure range from 0 - 1885 PSI, 0 to 13 MPa)
- Maximum Clamping force (Pressure range from 0 - 1885 PSI, 0 to 13 MPa)
- The Pulling cylinder stroke: ranging from 17.7-19.7 inches, 450~500 mm
- The die is divided into 6 heating areas. Adjustable temperature, ranging from 0~392 - 10F (0~200 - 10C) and temperature can be automatically maintained at a constant level.
- The traction operation can be controlled either manually or automatic.
- Electric power for die heating: 18 to 24Kw
- Die platform dimensions: 43.3" x 31.5" (1100 x 800 mm) (Can be customized)
- Clamp pressures & maximum pulling pressures adjustable by operator.
- Hydraulic Pump manufactured by "YUKEN", Japan.
- "OMRON" PLC elements utilized in the control system.
- Solenoid direction valves manufactured in Switzerland.
- "SMC" seals used in cylinder sealing system.
- Speed regulator valve manufactured in Switzerland.
- Electrical heating module utilizes solid-state, contactless relay and the heating element is made of aluminum alloy.
- Touch Screen LCD display control system utilizing "OMRON" products
- Pultrusion timer included (intermittent pultrusion & automatic die purge).
- Availability of PLC software & code with commands (English) to allow additional functions to be modified.
- Hydraulic fluid tank sealed with a filtered breather.
- All return fluid (especially case drain lines from the hydraulic pumps) filtered prior to return to the hydraulic fluid tank.
- Temperature control module utilizes "OMRON" products.
- Thermostatically controlled oil cooler with electric fan to maintain hydraulic fluid at the correct operating temperature.
- Return line filter with replaceable cartridge in oil return line to the tank.
- Variable rate pistons with pressure and flow compensation controlled by the puller circuit.
- Separate pump for the clamping function (both pumps driven from the same electric motor
