Roof Type Vacuum Tube Solar Collector With Solar Keymark

Name: Roof Type Vacuum Tube Solar Collector With Solar Keymark
Brand: Vanward, Vanward
SKU: 118305131
Availability: InStock

US$ 70 - 250 MOQ: 122 Pieces

Key Specifications

Type:

Other, Flat-Plate, Flat-Plate

Pressure:

Other, Pressurized, Pressurized

Circulation Type:

Other, Both

Zhongshan Vanward Electric Appliance Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Yantian/Shunde

Delivery Detail:

Delivery time depends on order quantity.

Type Other, Flat-Plate, Flat-Plate

Pressure Other, Pressurized, Pressurized

Circulation Type Other, Both

Heating System Thermosyphon (Passive)

Connection Type Split

Installation Freestanding

Housing Material Other, Aluminium Alloy, Aluminium Alloy

Certification Other, Solar Keymark, Solar Keymark

Capacity 1.2

Place of Origin Guangdong, China

Brand Name Vanward, Vanward

Model Number P-G/0.6-L/HG-1.8-2-E-Z

Specifications

Roof type vacuum tube solar collector with solar keymark
1.High efficiency
2.Black chrome heat-absorbing board
3.8%emissivity

Roof type vacuum tube solar collector with solar keymark

Model number: P-G/0.6-L/HG-1.8-2-E-Z

Copper Surface, Black Chrome Heat-Absorbing Board, Perfect for Sunshine

Copper surface, black chrome heat-absorbing board, good optical properties. Sunshine can be exchanged to heat energy in high efficiency.

Top Level Heat Efficiency, Enjoy Warmth from Sunshine

Solar absorption rate reaches 92%, emissivity is only 8%. Energy saving and low carbon release to make comfortable enjoyment.

Absorber measurements
Length x Width x Height(mm)	2000 x 1000 x 92
Gross Surface(Square meter)	2.0
Effective absorbing area (Square meter)	1.79
Collector pipe	Φ 22 x 0.5mm x 2
Banch pipe	Φ 8 x 0.6mm x 8
Water volume(L)	1.2
Absorber performance
Absorption(%)	≥ 92
Emission(%)	≤ 10
Max Working Pressure	15bar
Stagnation Temperature	146 °C
Collector material
Pipe	Copper
Sheet	Aluminium
Cover	Black chrome
Frame	Aluminium alloy 6063-T5
Glass	Tempered glass
Thermal insulator	Glass rock wool
Rear Wall thermal insulator	45mm of glass rock whool
Side Wall thermal insulator	15mm of glass rock whool
Rear sheet	0.4mm galvanized sheet
Seal assembly	EPDM
Packing Information
Net weight	35kg
Gross weight	36kg
Packing Size(Length x Width x Height)(mm)	2018 x 1006 x 110
Loading Qty(per 20"/40"/40:HQ)(pcs)	122/255/300
