Product Details
| Place of Origin | Taiwan | Brand Name | none | |
| Model Number | 301U | Type | Analog Camera | |
| Style | Other, USB interface | Sensor | CMOS | |
| Technology | Other | Special Features | Other, Shortest Borescope camera module |
Product Description
Model no.: 301U (with tube)
15mm Shortest Medical Endoscope Camera Module
5.5mm High Quality Medical Endoscope Camera Module
Waterproof wide view angle
- Small diameter 5.5mm
- The shortest length 15mm
- Medical stain steel tube
- High definition Optical lens standard
- Wide Viewing angle Fov (D):93°
- High resolution 300K pixel
- Integrate 6 white LED for brightness
- USB 2.0 interface & Plug & play functionality
- IP66 waterproof
Specification:
4.5mm(D) x 15mm(L) / USB 2.0 / UVC / wide view angle | |
ITEM | DESCRIPTION |
Model NO | 301U |
Image device | 1/8" High Color Sensor |
Effective Picture Element | 640(H)X480(V) |
Pixel Size | 2.5µm x 2.5µm |
AWB | Auto |
AGC | Auto |
AES | Auto |
Dynamic Range | 68dB |
S/N Ratio | 37dB |
Lens C nstruction | 3 Plastic +IR CUT |
Lens F/NO | F 2.8 |
Lens View Angle (Fov) | Fov (D):93° |
Focus Range | 15mm ~ 100mm |
Output System | USB 2.0 (UVC) |
Power input | VCC 5V ; LED 3.6V |
Light Source | 6pcs High Luminous White Color LED or NO Light Source |
Operating Temperature | -10°C to +50°C |
Operating Humidity | 30%~90%Rh |
TV Distortion | < 2% |
