Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Audio & Video Cable > Converter Box Switch Signal Signal Converters
Converter Box Switch Signal Signal Converters
US$ 1 - 50
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
none
Model Number:
converter box
Payment & Shipping
Payment Methods:
Port of Shipment:
SZ China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mini Mobile HD/SD DVB-T Receiver With Diversity TunerUS$ 1 - 100MOQ: 10 Pieces -
DVB-T2 DVB-T 2 Diversity Receiver for Car TunerUS$ 1 - 100MOQ: 10 Pieces
-
DVB-T and AVCUS$ 1 - 100MOQ: 10 Pieces
-
2 Diversity ISDB-T Full-Seg TV TunerUS$ 1 - 100MOQ: 10 Pieces
-
CA-C002, Extension Car Camera Cable DC + RCA Jack PlugNegotiableMOQ: 1 Carton
Place of Origin
China
Brand Name
none
Model Number
converter box
Type
Other, signal switcher
Application
Other, car camera
Color
Black
Packing
Carton Box
Outer Diameter
Customized
Connector Color
Other, black
Connector Type
Other, switch signal
Shielding
Other
Gender
Other
Converter Box
switch signal between SDI CVBS VGA HDMI DVI AHD TVI Signal Converters
| Signal Converters -- to upgrade your existing video system | |||
| Picture | Function | Items | Parameters |
| SDI TO CVBS convertor | * Professional HD Convertor from SDI to CVBS * industrial level SCALER * Change one channel SDI to one channel CVBS * Another SDI signal make amplification and output. |
SDI Input | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 |
| CVBS output | NTSC / PAL | ||
| Power | DC 5V~24V (3.5W) | ||
| Working Temp. | 0℃~60℃ | ||
| Storage Temp. | -20℃~70℃ | ||
| Humidity | 5~95%RH | ||
| Size | 116mm*110mm | ||
| SDI TO VGA convertor | * SDI t to VGA convertor * indutrial SCALER handle chips * make 1CH SDI signal change to 1CH VGA output * 1CH SDI zoom in signal output. |
SDI input | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 |
| VGA output | 800*600@60 1024*768@60 1366*768@60 1280*1024@60 1680*1050@60 1920*1080@60 |
||
| Power | DC 5V~24V (3.5W) | ||
| Working Temp. | 0℃~60℃ | ||
| Storage Temp. | -20℃~70℃ | ||
| Humidity | 5~95%RH | ||
| Size | 116mm*110mm | ||
| SDI TO HDMI convertor | * SDI t to HDMI convertor * indutrial SCALER handle chips * make 1CH SDI signal change to 1CH HDMI output * 1CH SDI zoom in signal output. |
SDI input | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 |
| VGA output | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 |
||
| Power | DC 5V~24V (3.5W) | ||
| Working Temp. | 0℃~60℃ | ||
| Storage Temp. | -20℃~70℃ | ||
| Humidity | 5~95%RH | ||
| Size | 116mm*110mm | ||
| SDI TO DVI convertor | * SDI t to DVI convertor * indutrial SCALER handle chips * make 1CH SDI signal change to 1CH DVI output * 1CH SDI zoom in signal output. |
SDI input | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 |
| VGA output | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 | ||
| Power | DC 5V~24V (3.5W) | ||
| Working Temp. | 0℃~60℃ | ||
| Storage Temp. | -20℃~70℃ | ||
| Humidity | 5~95%RH | ||
| Size | 116mm*110mm | ||
| AHD TO HDMI convertor | * AHD to HDMI convertor * indutrial SCALER handle chips * make 1CH AHD signal change to 1CH HDMI output * 1CH AHD zoom in signal output. |
AHD input | AHD: SD AHD: 720p25/720p30 AHD: 1080p25/1080p30 |
| HDMI output | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 | ||
| Power | DC 5V~24V (3.5W) | ||
| Working Temp. | 0℃~60℃ | ||
| Storage Temp. | -20℃~70℃ | ||
| Humidity | 5~95%RH | ||
| Size | 116mm*110mm | ||
| AHD TO CVBS convertor | * AHD to CVBS convertor * indutrial SCALER handle chips * make 1CH AHD signal change to 1CH CVBS output * 1CH AHD zoom in signal output. |
AHD INPUT | AHD:SD AHD:720p25/720p30 AHD: 1080p25/1080p30 |
| CVBS OUTPUT | NTSC / PAL | ||
| Power | DC 5V~24V (3.5W) | ||
| Working Temp. | 0℃~60℃ | ||
| Storage Temp. | -20℃~70℃ | ||
| Humidity | 5~95%RH | ||
| Size | 116mm*110mm | ||
| HDMI TO SDI convertor | * HDMI to SDI convertor * indutrial SCALER handle chips * make 1CH HDMI signal change to 1CH SDI output * 1CH SDI zoom in signal output. |
HDMI input | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 |
| SDI output | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 | ||
| Power | DC 5V~24V (3.5W) | ||
| Working Temp. | 0℃~60℃ | ||
| Storage Temp. | -20℃~70℃ | ||
| Humidity | 5~95%RH | ||
| Size | 116mm*110mm | ||
| DVI TO SDI convertor | * DVI to SDI convertor * indutrial SCALER handle chips * 1CH DVI signal change to 1CH SDI output * 1CH SDI zoom in signal output. |
DVI input | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 |
| SDI output | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 | ||
| Power | DC 5V~24V (3.5W) | ||
| Working Temp. | 0℃~60℃ | ||
| Storage Temp. | -20℃~70℃ | ||
| Humidity | 5~95%RH | ||
| Size | 116mm*110mm | ||
| CVBS TO SDI convertor | * CVBS to SDI convertor * indutrial SCALER handle chips for design * make 1CH CVBS signal change to 1CH SDI output * 1CH SDI zoom in signal output. |
CVBS input | NTSC/PAL |
| SDI output | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 | ||
| Power | DC 5V~24V (3.5W) | ||
| Working Temp. | 0℃~60℃ | ||
| Storage Temp. | -20℃~70℃ | ||
| Humidity | 5~95%RH | ||
| Size | 116mm*110mm | ||
| VGA TO SDI convertor | * VGA to SDI convertor * indutrial SCALER handle chips * make 1CH VGA signal change to 1CH SDI output * 1CH SDI zoom in signal output. |
VGA input | 800*600@60, 1024*768@60, 1280*720@60, 1280*800@60, 1280*768@60, 1440*900@60,, 1360*768@60, 1366*768@60,1280*1024@60,1600*1024@60, 1680*1050@60, 1920*1080@60,1366*768@75,1024*768@75 |
| SDI output | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 | ||
| Power | DC 5V~24V (3.5W) | ||
| Working Temp. | 0℃~60℃ | ||
| Storage Temp. | -20℃~70℃ | ||
| Humidity | 5~95%RH | ||
| Size | 116mm*110mm | ||
| TVI TO HDMI convertor | * TVI to HDMI convertor * indutrial SCALER handle chips * make 1CH TVI signal change to 1CH HDMI output * 1CH TVI zoom in signal output. |
TVI input | TVI: SD TVI: 720p25/720p30 TVI: 1080p25/1080p30 |
| HDMI output | 480i/576i 720p25/720p30/720p50/720p60 1080i50/1080i60 1080p25/ 1080p30/1080p50/1080p60 | ||
| Power | DC 5V~24V (3.5W) | ||
| Working Temp. | 0℃~60℃ | ||
| Storage Temp. | -20℃~70℃ | ||
| Humidity | 5~95%RH | ||
| Size | 116mm*110mm | ||
| TVI TO CVBS convertor | * TVI to CVBS convertor * indutrial SCALER handle chips * make 1CH TVI signal change to 1CH CVBS output *1CH TVI zoom in signal output. |
TVI input | TVI: SD TVI: 720p25/720p30 TVI: 1080p25/1080p30 |
| CVBS output | NTSC / PAL | ||
| Power | DC 5V~24V (3.5W) | ||
| Working Temp. | 0℃~60℃ | ||
| Storage Temp. | -20℃~70℃ | ||
| Humidity | 5~95%RH | ||
| Size | 116mm*110mm | ||
