Baoji Ti Gr5 hex socket tapered torx head DIN912 titanium screw
- 100000 Piece / Pieces per Month
- shanghai titanjin
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Shaanxi, China | Brand Name: | LIHUA | Model Number: | LH-077 |
Standard: | DIN |
Product Description
Baoji Ti Gr5 hex socket tapered torx head DIN912 titanium screw
Item Name | Hex socket tapered cyclindrical head DIN912/6912 Titanium Gr5 anode nuts bolts |
Material | Titanium, Titanium Alloy |
Grade | GR2, GR5 (Ti-6AL-4V), |
Specification |
Screw: M4-M24, Length 6~300mm |
Supply non-standard and special size according to customer's requirement | |
Standard |
1. DIN912, DIN913, DIN914, DIN915, DIN916, DIN931, DIN933, DIN934, DIN84, DIN963, DIN125, DIN 127, DIN433, DIN7991, 7984, 6921, 6923, 2. ISO 7380 3. JIS 4. BS etc |
Surface Treatment | Polishing, Milling, Anodised Gold, Blue, Green, Purple and Black |
Features | Light Weight, Excellent Resistance, Anti-Corrosion, Excellent Mechanical Strength etc. |
Applications | Equipment accessories: airplane, ship, bicycle, motorcycle, auto, medical, chemical, wheelchair, sports, anchor, weapon, etc. |
Test and Quality | 1. ISO 9001:2008 |
Payment | T/T, L/C, Westener Union, MoneyGram, Paypal |
Mechanical info about our Ti alloy bolts | |
Thread | Rolled thread for better fatigue resistance and avoid galling, Instead of cut thread |
Tensile strength | Heat treated to 950Mpa~1000Mpa |
Yield strength | 870Mpa~925Mpa (126,000psi~134,000psi) |
Hardness | 30 HRC-40HRC |
Shear strength | 500Mpa~550Mpa |
Elongation | 14%~18% |
Working temp | Up to 500°C |
FAQ |
Q1.--How can you ensure the product quality? --All products are manufactured according to ASTM standard (Bolts are according to ASME standard and DIN standard),and we make 100% inspection before shipment,also we can provide the MTC Material Test Certification. |
Q2.--Can you print our LOGO on the products? --Sure, and we welcome the customerized products. |
Q3.--Can we get the free sample? --Sure. |
Q4.--What about the payment terms? --T/T, L/C,Paypal,Western Union,Escrew and MoneyGram etc are all accepted. |
Q5.--Do you have your website? --Yes, Please click here. (Independent website) |
Q6.--What is the necessary information for a inquiry? --Product name, specification, material grade and quantity. |
