Fully automatic marble and granite bridge saw for sale
Introduction :
l This equipment adopts guide rail with highly precision grinding and manual scraping,the main parts are processed by heat treatment,the main beam and side beam are smoothed by oil immersed lubricating.But the surface of lifting guide rails are plated hardware treatment.
l It adopts by infrared to cut,the cutting speed by inverter control to achieve stepless adjustment.the head movements,table title up,rotation and position are used hydraulic transmission to move.And the main parts are imported with high quality,it can be cut by manually and fully automatic easily.
l It adopts PLC programmable control system and touch screen operator and combined with high precision encode positionning.
l The worktable is adopted at 90 degree rotation,and position at 360 degree,and there is no any effect by the environment in stable using.
l This machine is made of a good steel with high working accuracy and moving stable with long service life.
l It is applicable to cutting the valuable and large sized stone board for many specifications.
Parameter
max.blade of diameter |
φ400-700mm |
max.stroke for transverse |
3800mm |
max.stroke for longitudinal |
3800mm |
blade vertical stroke |
430mm |
max.titling degree for work-bench |
87° |
max.rotation degree for work-bench |
360° |
location degree for work-bench |
0°- 45°- 90° |
power of main motor |
18.5kw |
total power of machine |
23.5kw |
water consumption |
2m3/h |
water pressure |
>0.2 Mpa |
overall size for machine |
4800×5816×2350mm |
total weight for machine |
5800kg |
Detailed Picture
Packing size :4800×5816×2350mm
Container Load: 1set/20'
2set/40'
Outer Packing: nude
a, 1 years warranty.
b, OEM&ODM are welcome.
c, Delivery time is 7 days.
d, With assemble tools
Established in 1996,Laizhou Oriental Machinery Co.,Ltd. had engaged in the stone processing equipment industry for 20 years. We have the first-class designable talents and experienced technicians and are always specialized in developing and manufacturing the latest and most efficient stone processing machines.
Q1:Are you a trader or manufacture?
A1:we are manufacturer
Q2:Can i be a distributor of OMC?
A2: Of course you can.
Q3:Whar are the benefits of being a OMC distributor?
A3: -Special discount.
-Marketing protection
-Priority of launching new design.
Q4:How can i become a distributor of OMC?
A4: Contact us immediately for further details by sending us an inquiry
