16340 600mah 3.7v li-ion rechargeable battery

Specifications

16340 600mah 3.7v li-ion battery
1)Accept small order
2)High-quality materials
3)Factory Price
4)Custom design

16340 600mah 3.7v li-ion battery

Specification	li-ion battery
Type	Lithium-ion rechargeable cell
Model	TLH-14010408
Nominal voltage	3.7 V
Nominal capacity	600mAh
	discharge from 4.2V to 3.0V at 0.2C mA
Minimal capacity	570mAh
Max charge current	600 mA    1C
Charging method	charge with constant current 1C to 4.2V, then charge with constant voltage 4.2V  till charge current is less than 0.01C
Discharge cut-off voltage	3.0 V,  the over-discharge detection voltage of  PCM
Operating environment	Charging, 0°C ~ 45°C ;  65±20%RH
	Discharging, -20°C~60°C ;  65±20%RH
Storage environment	-20°C~45°C 65±20%RH
	storage for a long time(>3 months) and the storage condition shall be:<35°C;65±20%RH;3.7~3.9V
Weight (Approx)	40 g
Dimension (Max)	16x34mm

Advantages:

1, High energy density

2, High working voltage for single battery cells

3, Pollution-free

4, Long cycle life

5, No memory effect

6, Capacity, resistance, Voltage, platform time consistency is good

7, With short-circuit production function, safe and reliable

8, Factory price& High quality

9, Good consistency, low self discharge

10, Light weight, small size

Features:

1, Longer storage life than NiMH Batteries

2, Light weight and higher energy density than any rechargeable battery

3, Installed IC chip will prevent the battery pack from over charge and over discharge.

It helps protect battery chemistry integrity and prolongs battery life.

4, Installed polyswitch will cut off power if battery discharge current more than 6.6Ah

5, Perfect for building up battery pack for medical equipment Back-up or EPS Emergency Power

6, Supply which requires compact size and lighter weight

7, The battery module is wrap by PVC

Others:

1, OEM orders are available

2, Superior quality and cost-performance ratio

3, Tags, plugs and connectors are available

4, We could design and produce the battery pack with plastic shell and assembly procession for customized configurations is available (we could design and develop Li-ion battery according to your product work performance & structure apprearance)
