Help CenterSDD6A Diesel Locomotive
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Fuel Type:
Diesel
Place of Origin:
China
Model Number:
SDD6A
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Fuel Type
Diesel
Place of Origin
China
Model Number
SDD6A
SDD6A diesel locomotive is AC-DC diesel locomotive exported to Nambia, Angola and Madagascar.
This locomotive, with traction power from a diesel engine unit, is adopted Co-Co radial bogies with maximum operation speed of 120km/h and is suitable for passenger and freight transportation as well as shunting and marshaling operation.
Operation conditions:
Ambient temperature: -15°C~50°C
Altitude: 2000m
Max. Relative humidity : 90%
Max. gradient : 30‰
Climate conditions: Windy, sandy, dry, hot, dusty regions.
Main technical parameters:
| Min. curve radius | 80m |
| Model of diesel engine | Cummins QSK60-L1 |
Max. diesel engine service output |
1640kw |
| Transmission mode | AC-DC transmission |
Axle arrangement |
Co-Co |
| Wheel diameter | 914mm hub wheel |
| Locomotive Service weight | 96×1+ 3% t |
| Fuel tank volume | 4000L |
| Lubricant tank volume | 261L |
Cooling water capacity |
600kg |
| Sand capacity | 300kg |
| Gear ratio | 77/21 |
| Locomotive speed | The half-worn driving wheel diameter is calculated as 880mm. |
| Max . running speed | 120km/h |
| Max. running speed by constant power | 115km/h |
| Continuous running speed | 21.3km/h |
| Locomotive traction force at wheel rim | The half -worn driving wheel diameter is calculated as 880mm. |
Max. starting traction force |
314kN, limited by starting current |
