WLDH Model Stainless Steel Horizontal Powder Ribbon Blender
1, Powder Ribbon Blender/ horizontal Powder ribbon mixer/ horizontal Powder spiral mixer
2, U shaping design
3, Easy operate and maintance
4, Widely application
What is Powder
A powder is a dry, bulk solid composed of a large number of very fine particles that may flow freely when shaken or tilted. Powders are a special sub-class of granular materials, although the terms powder and granular are sometimes used to distinguish separate classes of material. In particular, powders refer to those granular materials that have the finer grain sizes, and that therefore have a greater tendency to form clumps when flowing. Granulars refers to the coarser granular materials that do not tend to form clumps except when wet.
Typically, a powder can be compacted or loosened into a vastly larger range of bulk densities than can a coarser granular material. When deposited by sprinkling, a powder may be very light and fluffy. When vibrated or compressed it may become very dense and even lose its ability to flow. The bulk density of coarse sand, on the other hand, does not vary over an appreciable range.
The clumping behavior of a powder arises because of the molecular Van der Waals force that causes individual grains to cling to one another. Actually, this force is present not just in powders, but in sand and gravel, too. However, in such coarse granular materials the weight and the inertia of the individual grains are much larger than the very weak Van der Waals forces, and therefore the tiny clinging between grains does not have a dominant effect on the bulk behavior of the material. Only when the grains are very small and lightweight does the Van der Waals force become predominant, causing the material to clump like a powder.
Description of Horizontal Powder Ribbon Blender
Powder is material composed of very fine particles that are not cemented together
Horizontal Powder ribbon mixer is a brand-new mixer. It is characterized in high efficiency, high degree of homogeneity, high load coefficient, low energy consumption, low pollution, little destruction to frangible material. It is suitable for mixing a wide range of materials such as powder-powder, power-liquid, especially for paste, thick materials.
Powder Ribbon Blender is composed of container, screw stirring paddles and transitional parts: the screw paddle are generally made into 1 layers or 3 layers, the outer screw converge is the material to the center from two sides, and the inner layer of screw conveys the material to the two sides from the center, so as to from convection mixing of powder which needs to add liquid, and paste material
Main Use and Application of Horizontal Powder Ribbon Mixer
The Horizontal ribbon mixer is generally used to mix viscous or adhesive powder material,or powder with liquid additive,or pasty material.Because it is difficult to clean viscous material,the machine is good at mixing material with large capacity and continuous demand.
This machine is applied in the industry of pharmaceutical,foodstuff,chemical,pesticides,plastic,pigment and cosmetics.
Standard configuration of Powder Blender Mixer
1. Drive Unit: Cycloid reducer or gear reducer
2. Motor brand: Siemens (made in China)
3. Gear box brand: Chinese Famous brand (Huaxing)
4. Bearings: Chinese Famous brand
5. Discharging valve: pneumatic flap valve (no dead angle when mixing).
6. Main Shaft Seal
Air-purged seal and stuffing seal for powder material
Mechanical seal for liquid material
7. Voltage and Hz
380V 3Phases 50hz or in accordance with it in the using place
8. Top Cover
Could be fully open so as to clean, with safety grid and limit switch to make sure safety operation for workers
9. Normal duty type: start the mixer first and then load the material
10.Packing in pallet or wooden case
Additional configuration
1. Driven unit: Many worldwide famous brands are for option: SEW, ABB, Siemens and so on
2. Bearings: NSK/TNT and so on
3. Heating/cooling jacket
4. Spraying system
5. Heavy duty type ( loading your material into the mixer first and then start the mixer)
6. Platform: we build the platform for you or we design it and you build it locally
7. Mixing system: including packing machine, bucket elevator, Sieve, screw conveyor and so.
Customizing according to client’s specific requirement
Features of KODI Horizontal Powder Ribbon Blender
1) Stable working, noiseless, easy to disassemble;
2) Available for continuous use;
3) Energy saving, compact structure, high precision transmission;
4) Strong loading capability and easy to assemble;
5) Less influenced by particle size and density;
6) With jacket or coil to heating;
7) Dedusting system and injection system for option;
8) Star/knife-edge/butterfly types valve for option;
9) Manual or pneumatic valve discharge.
Technical Parameters of Horizontal Powder Ribbon Blender
Model |
All volume |
Loads coefficient |
Electrical machinery power |
Size(mm)× Max-diameter ×High |
Equipment weight (kg) |
WLDH-0.1 |
0.1 |
0.4-0.8 |
3 |
1190×740×770 |
330 |
WLDH-0.3 |
0.3 |
0.4-0.8 |
4 |
2030×630×980 |
720 |
WLDH-0.5 |
0.5 |
0.4-0.8 |
7.5 |
2320×730×1130 |
980 |
WLDH-1 |
1 |
0.4-0.8 |
11 |
2800×920×1320 |
1700 |
WLDH-1.5 |
1.5 |
0.4-0.8 |
11 |
3180×1020×1550 |
1800 |
WLDH-2 |
2 |
0.4-0.8 |
15 |
3310×1120×1640 |
2100 |
WLDH-3 |
3 |
0.4-0.8 |
18.5 |
3750×1290×1820 |
3000 |
WLDH-4 |
4 |
0.4-0.8 |
22 |
4220×1400×1990 |
3980 |
WLDH-5 |
5 |
0.4-0.8 |
22 |
4220×1500×2100 |
4620 |
WLDH-6 |
6 |
0.4-0.8 |
30 |
4700×1610×2260 |
6180 |
WLDH-8 |
8 |
0.4-0.8 |
37 |
4420×2150×2470 |
8200 |
WLDH-10 |
10 |
0.4-0.8 |
45 |
5520×2960×2720 |
8920 |
WLDH-12 |
12 |
0.4-0.8 |
45 |
5720×3010×2840 |
9520 |
WLDH-15 |
15 |
0.4-0.8 |
55 |
5840×3540×2940 |
9950 |
Drawings of Horizontal Powder Spiral Mixer
Why Choose KODI
International high quality certification product chain
Manufacturer, more reasonable price
Solid technical support and after-sales service
Uphold the principle of “Customer Supreme”( Balance payment after equipments run normally)
Exports to more than 20 countries and regions, good customers feedback
One-stop service, customized exclusive project feasibility report
Changzhou KODI Machinery Co., Ltd. located in the birthplace of China drying equipment----Zhenglu Industrial Park, Changzhou City, Jiangsu Province which is 150km away from Shanghai city, with a comfortable environment and convenient transportation access.
KODI company is a professional manufacture of drying machine, which include Seaweed processing machine, Seaweed drying machine (Cottonii to carrageenan, Agar agar ), Spray dryer, Food ingredients spray dryer, Flavor spray dryer (Cocoa, Maltdextrin,Gum Acacia), Lab Spray dryer, Gelatin processing machinery, Gelatin drying machine (Hide and bone),Gelatin production line. we also deal in Horizontal powder ribbon blender, horizontal powder ribbon mixer, horizontal powder spiral mixer, high-quality fermentation tank, Bright tank , Extraction tank, concentration tank , evaporator and hermetic leaf filter,high efficiency stainless steel leaf filter etc.
We have implemented a strict and complete quality control system, which ensures that each product can meet quality requirements of customers. Besides, all of our products have been strictly inspected before shipment. Our products conform to international standards, such as CE, SGS.
KODI company also has a lot of top talent which have more than 15years of work experience, include research, design, manufacture and after sale service. Our products sell to all of the world (such as Australia, Malaysia, Indonesia, Vietnam, Philippines, Korea, Brazil, Chile, Peru, Argentina, Russia, Ukraine, South Africa, Cameroon, Sudan, Syria) and also have the good cooperation with the foreign client and vendor.
We are sure that our high quality products and excellent services will be appreciated by the growing list of satisfied customers. Contacting us is the first step to build a long and successful business relationship with us. Welcome!
Pre-service:
Act as a good adviser and assistant of clients to enable them get rich and generous returns on their investments.
1. Introduce the product to the customer in detail, answer the question raised by customer carefully;
2.Make plans for choice according to the needs and special requirements of users in different sectors;
Sale service
1. Ensure product with high quality and pre-commissioning before delivery;
2. Delivery on time;
3.Provide full set of documents as customer’s requirements.
After-sale service
Provide considerate services to minimize clients’ worries.
1.Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;
3.Train the first-line operators;
4. Examine the equipment;
5.Take initiative to eliminate the troubles rapidly;
6.Provide technical support;
7.Establish long-term and friendly relationship.
Service commitment
1. Provide clients one-year warranty to make sure the machine work well;
2.We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely;
3.Send every client a preferential quotation.
Special Notice:
In order to quota you the right horizontal powder ribbon blender/ powder ribbon mixer/ powder spiral mixer with best price, we would like to get the following information include in your inquiry:
-What is the raw material? Material related characteristic? Does it corrosive, strong basicity, or highly acid? Please confirm.
-What is the capacity per hour you need (kg/h)?
-What is the initial moisture and final moisture of finished products you require to get?
-What about the maximum heat temperature of raw material?
-What kind of fuel you use to heat the dryer? Natural gas, electricity, fuel oil or steam?
-Which equipment material do you like prefer? SUS304, SUS316L or Carbon steel?
-Provide us your country’s electricity information, such as phases, voltage, HZ?
-How about dust collect requirements?
-Other special requirements?
Frequently Asked Questions
Q: Can I visit your factory?
A: Yes. Many domestic and international customers visit our factory every year. Our company is near Shanghai.It only takes you about 1 hour to get Changzhou.Or we can visit you in Shanghai.
Q: What’s the quality of your products?
A:Parts of our products come with best quality, and our products passed CE certification, exported to lots countries around the world, such as Australia, Malaysia, Indonesia, Vietnam, Philippines, Korea, Brazil, Argentina, Russia, South Africa, etc. You can rest assured with the quality absolutely.
Q: What to do if the machine has a problem?
A:24 hours timely response of mail and phone calls. If the parts broken belong to non-artificial factors within 12 months, we offer free replacement. If beyond 12 months, customers should bear the freight back and forth and accessories cost.
Q: How long is the warranty of your equipment?
A: Our warranty period is one year generally.
Q: What is your payment term?
A: Our usual payment term is: 30% TT in advance, 70% TT before shipment. Other ways can also be received after we both sides discussion and agreement.
Q: Does your price include freight?
A: Our usual price is based on FOB Shanghai, if you request CIF, please give us your delivery port, and we will give you CIF price.
