PCB and PCBA Design Services in Shenzhen

PCB and PCBA Design Services in Shenzhen thumbnail-1
PCB and PCBA Design Services in Shenzhen thumbnail-2
PCB and PCBA Design Services in Shenzhen thumbnail-3
PCB and PCBA Design Services in Shenzhen thumbnail-4
PCB and PCBA Design Services in Shenzhen thumbnail-5
PCB and PCBA Design Services in Shenzhen photo-1
PCB and PCBA Design Services in Shenzhen photo-2
PCB and PCBA Design Services in Shenzhen photo-3
PCB and PCBA Design Services in Shenzhen photo-4
PCB and PCBA Design Services in Shenzhen photo-5
US$ 0.5 - 2.5 MOQ: 1000 Units
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
JT
Model Number:
JT-S-PCBA
Contact Supplier Request Quote Chat Now
Shenzhen Jointronic Technology Inc.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name JT
Model Number JT-S-PCBA
Base Material Fr4
Copper Thickness 1oz
Board Thickness 1.0-1.6mm
Min. Hole Size 0.075mm
Min. Line Width 0.075mm
Min. Line Spacing 0.075mm
Surface Finishing Hasl lead free

Customized pcba desing/assembly services

Professional pcba manufacturer in shenzhen

As professinal consumer electronic Manufacturer for over 8 years, We continuously adopt new technology, improve manufacturing process and reinforce scientific management
to cope with the dynamic and fiercely competitive electronic industry.
Our core principle is "Customer First". Quality is the guideline for everything that we do. Total management
solutions enable us to pursue perfection. Tailhoo will provide customers with fast delivery, competitive prices,
superior quality and satisfactory one stop services.
we persist in innovation to strengthen our competitive advantages.We cater to customer needs by offering
the best products and solutions. We have confidence that with the support of all our professional engineers
team, we will keep growing and bring maximum profit to you.

Our service :

One-stop service for Product design , PCBA design, PCBA layout, PCBA manufacture, IC/Components purchasing,
PCBA assembly, test, packing and PCB delivery;
PCBA Copy, IC Decord, Reverse Engineering;
Electronic Design(schematic design and enclosure design).

PCB and PCBA assembly files requirements :
  1. Gerber Files, PCB sample for reverse engineering and pcb copy
  2. Board Specification
  3. BOM (Bill of material) For Assembly
PCB Production Capability :


Specification

Process capability

Type

Single-sided, double-sided, multi-layer

Materials

FR-4, CEM-1, CEM-3, high-frequency halogen-free, aluminum, iron base, copper base

Finish Board Thickness

0.2mm-6.0mm

Copper substrate thickness

18um,35um,70um,105um

Surface

Hasl(LF), Electroless nickel gold, spray tin, chemical gold, carbon oil, gold finger, OSP,

immersion tin, immersion silver, OSP(Entek)

Maximum size

600mm*700mm

Solder Mask

Green, Black, Blue, White, Red, Yellow

Board Warp

Single-Sided≤1.0% Double-Sided ≤0.70%plywood≤0.50%

The minimum thickness & Tolerance

0.2mm±0.08mm

Minimum line width / line Gap & Tolerance

Spray tin plate:0.1mm±20%(4mil±20%)



Gold Plate:0.076±20%(3mil±20%)

Copper from the Edge

0.5mm(20mil)

Hole margin line edge

0.3mm(12mil)

Minimum aperture & Tolerance

0.2mm±0.076mm(16mil±3mil)

Minimum Pitch & Tolerance

0.4mm±0.076mm(16mil±3mil)

Hole copper thickness

20-25um(0.79mil-1.0mil)

Positioning hole deviation

±0.076mm(±3mil)

Chong Min hole diameter

FR-4 Board Thickness 1.0mm (40mil) the following:1.0mm(40mil)



FR-4 Board Thickness 1.2-3.0mm(48-120mil):1.5mm(60mil)

Min Chong Fang slot specifications

FR-4CEM-3 Board Thickness 1.0mm(40mil) :0.8mm*0.8mm(32mil*32mil)



FR-4 Board Thickness 1.2-3.0mm(48-120mil):1.0mm*1.0mm(40mil*40mil)

Screen Printing Line bias

±0.076(±3mil)

Min pad window

0.076mm(±3mil)

Minimum green oil Bridge

±0.76mm(±3mil)

If kindly provide your Gerber Files, PCB Specification and Bom List to us, we will quote for you asap.

Products

Products are applied to a wide range of High tech industries such as:  telecommunication, computer
application, lighting, industrial control,security, power and consumer electronics, ect. products exports
to American, Canada, Europe counties, Africa andother Asia-pacific countries.

PCB and PCBA Design Services in Shenzhen

Advantage

1.One stop service
2.PCBA Have the comprehensive quality control system
3.PCB/Chipest good price
4.PCB quick turn delivery time
5.PCB certification(ISO/UL/RoHS)
6.8 years experience in exporting service
7. Low MOQ/MOV
8.PCB is high quality.Strict through the QA/QC,fly porbe ,Etesting
