Reliable 3 Phase Online LF UPS 380V 60kva

Reliable 3 Phase Online LF UPS 380V 60kva thumbnail-1
Reliable 3 Phase Online LF UPS 380V 60kva photo-1
US$ 4,158 - 4,158 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OX
Model Number:
GP33-60i
Contact Supplier Request Quote Chat Now
Green Power Electronic (Shenzhen) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name OX
Model Number GP33-60i
Phase Three Phase
Protection Other, overcurrent,over voltage, shortcircuit, unbalanced load
Weight 600kg
Output Voltage 3x380/220 vac ± 1%
Type On-line
Application Other, medical, mining, banking, transportation, computer room, telecom

Specifications

Key Features of Reliable 3 phase Online LF UPS 380V 60kva
1. Independent R&D technology;
2.Simplified Circuit Borad design.

Advantages of GP33-60i 3 phase online LF UPS 380V 60kva



1. The low frequency UPS is mature electric equipment and the reliability is very high and well known.



2.Its simplified circuit board design allows us to use small quantity of PCB (5 PCB: control PCB, rectifier PCB, Bypass PCB, IGBT drive PCB and display PCB), and all these PCB can be used in different models. This helps you and your customers to keep small quantity of spare parts for support.  The PCBs are compatible with other capacities, for example the control PCB is the same for all the models up to 200 kva. The technicians only learn about 1 model, and after this they will know all powers from 20 to 200kva.



3.  Full support and 100% Intellectual Property allows flexible changes if the customer needs, like names on display, different calibrations, different voltages, better support etc.



4.  Less stock for spare parts, easy connection.



5.  Parallel ready: all our units come ready to work in parallel, and no need to add PCB or pay more for this function.



6. The control is totally digital. This means that all the calibrations and settings are digital, and we don’t use potentiometers to do the calibrations which assures that all the settings will not change through the time, since the potentiometers may be affected by vibrations.



7.  ECO mode for improving the  efficiency to near 98%.



8.  Isolation transformer is included for all models.



9.  Transient protection: our unit has  transient protections to protect the UPS and the load for transients which reduces the probability of  UPS failures.



10.  Our unit can work all the time even with wrong polarity on the phases for rectifier input.



11.  Internet Support: just need connect a SIM card to this UPS, and we will be able to diagnose the UPS and help you offer prompt solution to your customers. (optional)



Specification Sheet of  GP33-60i 3 phase online LF UPS 380V 60kva





specification   model GP33-20i GP33-30i GP33-40i GP33-60i GP33-80i GP33-100i GP33-120i GP33-160i
general
capacity 20kva /      16 kw 30kva /      24 kw 40kva /       32 kw 60kva /       48 kw    80kva /     64 kw 100kva /     80 kw 120kva /     96 kw 160kva /     128 kw
features scalable power / ups parallel ready with another of the same capacity / 100% microcontroller / redundant forced ventilation / immune to phase rotation input / dual input type input (optional)
estimated useful life 20 years
efficiency ac / ac  90%
transfer time 0 sec
design technology true online (double conversion), inverter based on igbt's
input
voltage (*) 3x380/220 vac ± 20%
frecuency (*) 50hz ± 10%
power factor 0.8
technologie RECTIFIER 6 PULSES
lead wires (*)  3 phases +neutral+ground
output
voltage (selectable) (*) 3x380/220 vac ± 1%
frecuency 50hz ± 0.1%
waveform type sine wave generated by the inverter with high frequency pwm
harmonic voltage distortion t.h.d <2%  for linear load / <5%  for non-linear load
  crest factor   3  :  1
power factor 0.8 0.8
overload recovery.  automatic
isolation transformer dry type for inverter - voltage 380v/220v
voltage regulation ± 1% for balanced load.
overload capacity (*) 125% for 12 minutes. / 150% for one minute
 wires (*)   3 phases +neutral+ground
batteries
type (*) sealed and maintenance free. technology vrla (valve regulated lead acid)
autonomy at full load (*) 5 to 15 minutes.   extended range capability.
typical recharge time. 4 hours 90%
battery management. auto-test, adjustable battery transfer point and settings of alarm.
battery protection. breaker protection. turn the system off when the battery is low.  battery  test. smart charger.
charger soft start to full load. current limiter for charging batteries.
protections
hardware protection breaker (termomagnetic) for input, output, battery(in battery case for >=100kva),fast acting  bypass fuse, fast-acting fuses in dc and bypass, fan, redundant power supply, temperature sensors, on-off switch, audible alarms.
bypass static, solid state, automatic and uninterrupted operation manual for maintenance breaker, external bypass (optional)
emergency breaker. local EPO and / or remote
monitoring and communications
front panel standar: LED display voltage, current etc  optional: lcd display 240 * 128   reading electrical parameters. touchscreen. led mimic.
alarms audible and visual alarms for non-normal conditions.
communications rs232 serial port. "snmp-rj45" for remote monitoring (optional). gprs module for remote monitoring viacellular network (optional).
 ups  conditions
temperature 0°c to 40°c
relative humidity. 0 to 95% noncondensing
audible noise <60 db at 1.5 meters  <65 db at 1.5 meters
batteries conditions (recommended)
temperature 0°c to 25°c
relative humidity. 0 to 95% noncondensing
dimensions and weights
ups dimensions in mm (front x hight * deep) 540x1120x 620 540x1120x 620 660x1550x865 660x1650x865 690x1650x900 1100 x 1800 x 900 1100 x 1800 x 900 1200 x 1900 x 900
battery cabinet dimensions mm, depend of backup time (front x hight * deep aprox) 270x1125x 774 270x1125x 774 432x1550x897 432x1550x897 432x1550x897 800 x 1900 x 900  800 x 1900 x 900  800 x 1900 x 900
ups weight in "kg" 225 273 500 600 700 850 850 850
battery case weight in "kg".  59 59 105 105 125 240 240 240
