Help CenterTouch Screen Display UPS LCD
US$ 30.2 - 32
MOQ: 1000 Sets
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CDP
Model Number:
RU Smart 1010
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
CDP
Model Number
RU Smart 1010
Phase
Single Phase
Protection
Lightning
Output Voltage
110/115/120VAC or 220/230/240VAC +/- 10%
Type
Line Interactive
Application
Telecommunications
Line Interactive UPS, 750VA/350W,
Black Cabinet + I-287 LCD White Panel,
W/AVR (Boost II + Buck I),
Nema5-15R outlets * 5pcs AVR regulated + 5pcs surge protected,
W/ 96*35mm Transformer, 16AWG wire (1.2M),
W/ COAX protector (The one that CDP uses.),
W/ USB port, W/ Software, W/ USB charger*4pcs(total 5V 2.1A),
W/ 12V/7AH*1pc
| CDP Model No. | RU Smart 751 | RU Smart 1010 | ||
| Capacity | 750VA/350W | 1000VA/500W | ||
| Input | Voltage | 110/115/120Vac or 220V/230/240Vac | ||
| Voltage Range | -30%+25% | |||
| 120V System: 80Vac-145Vac (Tolerance: 85Vac-150Vac is okay) | ||||
| 220V System: 154Vac-290Vac | ||||
| Frequency | 50Hz or 60Hz (Auto-Sensing) | |||
| Output | Voltage Regulation AC Mode | 110/115/120VAC or 220/230/240VAC +/- 10% (220V: 208-250Vac) | ||
| Voltage Regulation Battery Normal | 110/115/120VAC or 220/230/240VAC +/- 10% | |||
| Frequency | 50Hz or 60Hz +/- 1Hz | |||
| Waveform | Simulated Sinewave | |||
| Transfer Time | < 6ms(Typical) | |||
| Outlet: Nema 5-15R | 5pcs AVR regulated + 5pcs surge protected | |||
| Battery | Voltage | 12VDC | ||
| Type | 12V/7AH | 12V/9AH | ||
| Recharge Time | 5hr to 90% after complete discharge | |||
| Safety Protection | Over Charge & Over Discharge Protection | |||
| Advanced Battery Management | ||||
| Back-up Time (Load with 1 PC) | 20 Minutes | 30 Minutes | ||
| LCD Display | I/P & O/P Voltage & Frequency, Load %, Battery % | |||
| Audible Alarm | Battery Mode | Two short tones every 8 seconds | ||
| Low Battery | Four short tones every second | |||
| Overload | Buzzer: Beeping continuously | |||
| Fault | Beeping continuously | |||
| Function | AVR (Automatic Voltage Regulation) | 2 Boost + 1 Buck | ||
| COAX Protector | Yes | |||
| DC Start Function | Yes | |||
| Auto Restart UPS | Yes | |||
| Over/Under Voltage Protction | Yes | |||
| No-load Cut-off (Green Mode) | Yes | |||
| Silence The Audible Alarm | Yes | |||
| Off-mode Charging | Yes | |||
| Short Circuit Protection | AC Fuse and Electronics Circuit(Line mode) ; Electronics Circuit(Back-up Mode) | |||
| Lightning/Surge Protection | 99 Joules (110/115/120Vac) / 175 Joules (220/230/240Vac) | |||
| Communication Interface | USB Charger *4pcs (Total 5V 2.1A) | |||
| Communication Port | USB Port | |||
| Management Software | Shutdown Software (Supporting Windows 98/NT/2000/Me/XP/2003/Vista/7/8) | |||
| Environment | Operating Temperature | 0° C - 40° C (32°F~104°F) | ||
| Humidity | 0-95% (No Condensing) | |||
| Acoustic Noise | <40 dB at 1M | |||
| Physical | Dimension(W*D*H) | |||
| Design, Manufacture, Service | ISO9001-2008 | |||
| Warranty | 1 Year | |||
