QGF Series Full Automatic Barrel Filling Production Line
- 10 Set / Sets per Month
- Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Hongma | |
| Model Number | QGF | Condition | New |
Product Description
Specifications
Full Automatic Barrel Filling Production Line1.Barrel filling production line.
2.High capacity.
3.Reasonable price.
QGF Series Full Automatic Barrel Filling Production Line
Introduction of Production
This filling line specially produces 5 gallons barreled drinking water, those types(barrel/hour) are: 80 type, 150 type, 300 type, 450 type, 600 type, 900 type. It integrates bottle washer, filler and sealer into one unit. In order to achieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and bleaching are used in bottle washer, washing solution can be used circularly. The sealer can seal barrel caps automatically. This line equips with water spraying device to sterilize capes of bottles in order to ensure those caps are aseptic and healthy, also this line can automatically carry out barrel feeding, washing, sterilizing, filling, capping, counting and products discharging, it is a new kind of barreled water auto-production line, which intergrates mechanism, electricity and pneumatic technologies together.
Main Technical Spedifications
Model | QGF-80 | QGF-150 | QGF-300 | QGF-450 | QGF-600 | QGF-900 |
Filling Heads | 1 | 1 | 2 | 3 | 4 | 6 |
Volume(L) | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
Barrel Size(mm) | 270x490 | 270x490 | 270x490 | 270x490 | 270x490 | 270x490 |
Capacity(B/n0 | 80 | 150 | 300 | 450 | 600 | 900 |
Gas Pressure | 0.4-06. | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.6 | 0.7 |
Gas Consumption(m3/min) | 0.37 | 0.37 | 0.6 | 0.8 | 1 | 1.2 |
Motor Power(kw) | 1.38 | 1.75 | 3.8 | 3.8 | 7.5 | 9 |
Motor Voltage(V) | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ |
Weight(kg) | 500 | 700 | 1200 | 1600 | 2000 | 3500 |
Overall Dimension(mm) | 2500x1100x1600 | 2800x1100x1600 | 3800x1300x1600 | 4200x1600x1600 | 4800x1800x1600 | 4200x2300x1600 2800x1000x1600 |
