Specifications
The drink mixer is for mixing CO2, syrup & water to make carbonated drink.material:S.S304
The drink mixer is key equipment of producing carbonated drink. It is designed and
made to improve the proportion of water, syrup and carbon dioxide.
It adopts foreign advanced technology-a static mixer to lighten water layer, increase carbonizingtime and assure the mixing result.
It adopts a high-quality water pump, electrical equipment and other parts to form a complete automatic control system.
QHS series drink mixer is designed and made for improving the proportion of water,syrup and carbon dioxide
Drink mixer is made with the newest technology introduced from Japan. It is in the leading position comparing with similar products in china. The mixer is mainly suitable for mixing process of all kinds of carbonated soft drink.
It is also used in mixing of slurry drink,fermented drink and other drinks.
Technology Parameter:
Model |
QHS-1500 |
QHS-3000 |
QHS-4000 |
QHS-6000 |
Production capacity |
1500Kg/H |
3000Kg/H |
4000Kg/H |
6000Kg/H |
CO2 rate |
>2.6 |
|||
Chilled water inlet temperature |
0-4 |
|||
Power |
1.1Kw |
1.1Kw |
1.1Kw |
1.1Kw |
Weight |
600Kg |
800Kg |
1300Kg |
2500Kg |
Overall dimension |
1030x1180x1930mm |
1550x1050x2000mm |
1650x1300x2000mm |
1900x1300x2000mm |
