High oil yield palm oil production line | palm oil press production line
2. Sterilizing section of palm oil production line : palm fruit bunch are airtight sterilized in sterilizer. The purpose is to prevent enzymes broken down, avoiding FFA content in oil further increase; easy threshing machinery; pretreatment peel, prepared for the follow-up processing; pre-conditioning stone, reducing the damage kernel.
3. Threshing section of palm oil production line :The purpose of threshing is to separate oil palm fruit from the fruit bunch through strong vibration, Threshing equipment is revolving drum thresher. The separated oil palm fruit is ejected then into the pressing section. Empty fruit bunch be ejected to the yard from the other side of the revolving drum, or shipped out from the plant as palm orchards slipcover to recycling use, or burning in the locale as fertilizer for agricultural land.
4. Pressing section of palm oil production line:Before pressed, oil palm fruit first be carried out cooking, sterilized fruit must be re-heated to make the pulp soft and damage pulp cell structure. Then enter into continuous screw press. After pressing, oil palm fruit is divided into two parts: oil, water, solid impurities miture and the press cake (fiber and nut). Oil, water, solid impurities miture inflow to oil purification section by the crude oil gutter; pressed cake into the fiber- recovery section by breaking screw conveyor.
5. Clarification section of palm oil production line:Machine-pressed crude oil first diluted with water washing, the fiber material removed from the oil through settlement and filtration, and then carry out continuous settlement, the whole divided into two parts: oil and sediment. Through centrifugal separation and vacuum drying, oil is pumped into the storage tank for storing; oil sediment by filtration and dirt oil separation, oil proceeds second settlement, dirty oil miture proceeds clarification separation, skim oil then be carried out a second settlement, sewage pumps to sewage treatment pond for dealing.
6. Finished oil storage and transportation section of palm oil production line: Finished crude oil is stored in storage tanks, the capacity of oil storage tank is two 1000 tons tanks, serve oil shed loading and issuing oil regularly to outside. Finished crude oil generally be stored and transported between at 32 C- 40 C, the working temperature of the palm oil should be at 50 C to 55 C. to prevent overheating.
7. Fiber separation section of palm oil production line: Press cake broken by breaking screw conveyor and then transported into the fiber separation air net and fiber polishing roller for fiber separating. The separated fiber material is sent to the boiler room as fuel; the separated stone is transported to stone warehouse by pneumatic conveying system for temporary storage.
8. Kernel recovery section of palm oil production line : the stone needs intenerate tempering before being broken, the intenerating stone be divided into two or more petal by corrugated crusher, kernel was released. The broken miture enters into broken miture separation system; separation system adopts two stage separation and water separation. After separation, shell is sent to the warehouse for temporary storage, as boiler room fuel when necessary; the moisture content of separation kernel falls to below 7% through the hot air to dry. Dried kernel is sent to kernel storage warehouse for storing.
9. Sewage treatment section of palm oil production line : the waste water has high organic matter content, biochemical oygen demand BOD is about 25000ppm, required by qualified deal before emissions. Pool sewage treatment system is the most used and effective treatment. This treatment system is cost-effective, only needs adequate space, less investment costs.
containers, wooden package and simple package for palm oil production line or according to customer requirements.
Pre-sale services:
Act as a good advisor and assistant of clients; enable them to get rich and competitive
from the returns of their investment.
1) Select suitable equipment model.
2) Design and manufacture products according to clients’ special requirements.
3) Train technical personnel for clients.
4) Professional suggestion for customer
Services during the sale:
Respect clients; devote ourselves to improving the total value of clients.
1)take photos(including raw material, semi-products, final products, and loading products)
2) Pre-check and accept products ahead of delivery.
3) Prepare all clearance documents, so that the customer clearance smoothly.
After-sale services:
Provide considerate services to minimize clients’ worries.
1) Provide civil engineering drawings of the equipment.
2) Free training(including installation,maintenace) to every customer.
3) Install and debug the equipment, ensure the dryer running smoothly.
4) Examine the equipment regularly.
5) Take initiative to eliminate the troubles rapidly at site.
6) Distribute the guarantee fittings door-to-door.
7) Provide technical exchange and support.
8) Provide maintenance for big items.
9) The most preferential prices to provide customers the quick-wear parts.
Henan Doing Mechanical Equipment Co., Ltd is a comprehensive enterprise related to manufacture, marketing, installation and after sale service etc.Doing company is committed to developing and manufacturing of all kinds of large scale and small scale equipments. Doing company is one of the professional agricultural machine supplier. With good reputation and high quality products, we focus on supplying customer perfect technology and professional service.
palm oil machine business scope:
0.5-1tph small scale palm fruits processing machine;
1-20tph small scale palm fruits processing machine;
30-120tph small scale palm fruits processing machine;
1-600tpd palm oil refinery machine;
1-600tpd palm oil fractionation machine;
palm kernel oil extraction machine;
1. Q: Which kind of materials can be processed?
A: All kinds of oil seeds. For example, rice bran, corn germ, cottonseeds, peanut, sunflower, soybean, rapeseed, etc.
2. Q: What's the capacity?
A: 5-2000 tons per day.
3. Q: The materials of our machine?
A: The stainless steel and carbon steel.
4. Q: How long is the warranty?
A: 1 year.
5. Q: Can you install the machine in local place.
A: We will send our engineers to local place to help installing the machine.
6. Q: How to operate the machines?
A: Our engineers will train the worker how to operate it after running.
7.What kind of vegetable oil processing production equipment we can supply?
vegetable oil production equipment for pretreatment line.
vegetable oil production equipment for prepress or press line.
vegetable oil production equipment for cakes solvent extraction line.
vegetable oil production equipment for refinery line.
Our customer:
We have customers from all over the world like Uzbekistan, Kyrghizstan, Kazakhstan,and Canada, Chile, Argentina, Ethiopia, Zambia,Nigeria, Russia, Turkey, more than 30 countries and areas.
If you are interested in palm oil production line ,please feel free to contact us !
