GF-3100 series is a simplified screen printing machine product integrated with advanced mechanical, electrical and pneumatic technologies. The concept of this product is simple and practical, as a result, leading to economical production cost, with high efficiency output
This series of screen printing machine features:
- High production speed
- Compact machine dimension, space efficient
- Labour and material saving with simple operation and short set up time
- Equipped with photocell sensor tracking system, ready for "Re-Print" on multi colors
- Able to print multiple tapes simultaneously which will increase productivity
- Able to print on dark colour material tapes with sharp, solid and discrete effects on the images
- Strong concealment effect and colourfastness
- Colors combination to be choosen from 2~8 colors
- Suitable to print with all kinds of roll form material, including all fabrics and paper.
- Able to print double side with additional device
PARAMETER TABLE
1 colours |
2 colours |
3 colours |
4colours |
|
Single-Sided Mode |
GF-3110 |
GF-3120 |
GF-3130 |
GF-3140 |
Printing Area |
L X W: 400mm X 300mm |
|||
Max. Printing Speed |
11m/min. |
7m/min. | 7m/min. | 7m/min. |
Registration Precision |
0.05mm |
|||
Suitable Materials |
Polyester tape, nylon tape, cotton tape, herringbone tape, adhesive tape, and roll of paper, heat transfer film, etc. |
|||
Power |
1 phase 220V |
3phase 380V |
3phase 380V |
3phase 380V |
Compress Air Supply |
Input: 1Mpa Exhaust Volume: above 1m3/min. |
|||
Output |
8kw |
10kw | 15kw | 20kw |
Dimension(LxWxH) |
2700x1150 |
8300x1100 x1300 mm |
10700x1100 |
13500x1100 |
Net Weight |
750 kg |
1500 kg |
2000 kg |
2500 kg |
According to customer location, we can provide local after sales service
All machines comes with 1 year spareparts warranty, excluding consumables and operational error
Note: Ultrasonic horn comes with 3 months warranty only.
Export Fumigated Wooden Case
- Ex Work
- FOB
- CFR
- CNF
- SEA FREIGHT
- AIR FREIGHT
- ROAD FREIGHT
-
Automatic Satin Ribbon, washing Care Label Screen Printing Machine
