Aerodynamic Performance Test Devices for IEC60665

It is designed according to the requirement of IEC60665. Mainly use for aerodynamic performance of the outward exhaust kitchen ventilators. Test programs: air flow , wind pressure and so on. 8 sampling point.

Technical parameter:

Power supply:AC220V 50Hz, power:5KW

Air flow:0.8~25m³/min

Micro pressure meter range：10~500Pa

Accuracy:＜50Pa,±0.25Pa; 50~100Pa, ±0.5Pa;＞100Pa,±1Pa

Air pressure sensor accuracy:±150Pa

Temperature range:10~50°C,accuracy +0.1°C

Humidity range：0~00%RH

Voltage range is 0-300V, the measurement accuracy is 0.3%+0.2% full scale

Current range is 0.2-5A, the measurement accuracy is 0.3%+0.2% full scale

Power range is 150-300W, the measurement accuracy is 0.3%+0.2% full scale

Time range is 0-99.99H,the measurement accuracy is within 0.1S.
