360 View Reverse Car Rearview Camera System

Name: 360 View Reverse Car Rearview Camera System
Brand: CAR GENERAL
SKU: 118123239
Availability: InStock

US$ 5 - 7 MOQ: 100 Pieces

Key Specifications

Type:

Reverse Camera

Voltage:

DC 12V

Power:

Shenzhen Sunway Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Type Reverse Camera

Voltage DC 12V

Power 4W

Car Make ALL CAR

Place of Origin Guangdong, China

Brand Name CAR GENERAL

Model Number SW-165GH

Warranty 18 Months

Car 18.5mm PARE car camera for reversing car:

CAR REARVIEW CAMERA
Image sensor :	OV7974 HD CMOS (OV 7950&PC1030 is optional)
Signal system	NTSC/PAL
Effective pixel:	PAL: 648(H)× 488(V) NTSC: 648(H)× 488(V)
Effective Pixels	648X488
Definition:	420 TV Lines
Mini illumination	0.05Lux
Lens angle	120degrees
Sensitivity	3.0V/Lux-sec@5600K
Horizontal view angle	90degrees and 120 degrees is optional
Video output	RCA connector,1.0vp-p,75ohm
Current consumption	the maximum :95mA
Power	DC12V
Night vision distance	0-5m
Operating Temperature(Deg C)	-30-+65RH95%Max)
Storage Temperature(Deg C	-40-+80(RH95% Max)
AGC	to be automatic
White balance	to be automatic
The backlight compensation	to be automatic
Wide-Angle, Waterproof, Anti-shake and Anti-mist.
