Home > Electrical & Electronics > Power Supply & Distribution > UPS > Advanced MCU Microprocessor Control Technology EX 6~20KVA UPS High Frequency Online Ups With 1 Hour Backup

Advanced MCU Microprocessor Control Technology EX 6~20KVA UPS High Frequency Online Ups With 1 Hour Backup

Name: Advanced MCU Microprocessor Control Technology EX 6~20KVA UPS High Frequency Online Ups With 1 Hour Backup
Brand: WARD
SKU: 118108269
Availability: InStock

Advanced MCU Microprocessor Control Technology EX 6~20KVA UPS High Frequency Online Ups With 1 Hour Backup thumbnail-1

Advanced MCU Microprocessor Control Technology EX 6~20KVA UPS High Frequency Online Ups With 1 Hour Backup photo-1

US$ 145 - 850 MOQ: 1 Unit

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

WARD

Model Number:

EX6~20KVA UPS

Contact Supplier Request Quote Chat Now

Zhong WARD (Shenzhen) Power Supply Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name WARD

Model Number EX6~20KVA UPS

Phase Other, Single Phase, Single Phase UPS

Protection Other, over voltage, over load, over current, over charge, Short Circuit

Weight 35~85KG

Output Voltage 220/230/240VAC, 220/230/240VAC

Type On-line

Application Other, bank, hospital,traffic,ATM

Advanced MCU microprocessor control technology EX 6~20KVA UPS High Frequency Online ups with 1 hour backup

Product Description

Applications:

EX series 6KVA-20KVA high frequency online UPS is specially designed for servers, data-center critical network devices, sensitive electronic equipment, telecom, bank, hospital bureau, traffic, traffic, public security, Army and so on.

Feature:

* High Frequency Online EX6~20KVA UPS

*Large Blue Ground LCD digital display shows Detailed Real-Time UPS Status and parameters.
*Output Voltage, Frequency parameter and bypass function can be set via the display.

*Advanced MCU microprocessor control technology and DSP technology, ensure long life reliability.
*192vdc battery input voltage.

*Wide input AC voltage range, Zero transfer time
*True online double conversion technology.
*N+X Parallel Redundancy
*Excellent Protection against over voltage, over load, over current, over charge and so on.
*Input L and N lines reverse wiring detection, Auto start when AC back.
*DC start function, Input PFC revise function.
*Humanization bypass output can be adjustable.
*Smart RS232 communication with monitoring software
*Intelligent slot available for AS-400 Dry contact and SNMP card Remote control
*Available to work with generators.

*Lightning, surge, short circuit, Network/fax/modem surge protection

Specifications:

Online UPS MODEL		EX6K		EX10K	EX6KL	EX10KL	EX3110KL	EX3115KL	EX3120KL
CAPACITY	VA/W	6KVA/4.8KW		10KVA/8KW	6KVA/4.8KW	10KVA/8KW	10KVA/8KW	15KVA/12KW	20KVA/16KW
INPUT	Nominal Voltage	220/230/240VAC					380VAC
	Voltage Range	120-275VAC					210-475VAC
	Frequency Range	46-64Hz: 50Hz, 60Hz auto sense
	Phase	Single phase with Ground					Three phase (4 Wires+Ground)
	Power Factor	>=0.99					>=0.95
OUTPUT	Voltage	220/230/240*(1±1%)VAC
	Frequency	50/60Hz(Adjustable) 50Hz AC Mode: Follow AC Mode (AC Range 46~54Hz); Battery Mode: 50Hz(1±0.1%) 60Hz AC Mode: Follow AC Mode (AC Range56~64Hz); Battery Mode: 60Hz(1±0.1%)
	Wave Form	Pure Sine Wave
	Power Factor	0.8
	Harmonic Distortion	=<2% THD (Linear Load), =<6% THD (Non-Linear Load)
	Overload Capacity	Normal when load < 105%; 105%-125% for 1 min, 125%-150% for 30sec
	Current Crest Ratio	3:1
	Connections	Terminal block
Efficiency	To AC Mode	88%					85%
	To Battery Mode	up to 90%
Battery	Type	Sealed free maintenance lead acid battery
	Nominal DC voltage	Built in batteries 12v7.2ah*16pcs			192VDC	192VDC
	Quantity	16pcs	16pcs		Depends on requested back-up time	Depends on requested back-up time
	Back-up Time (Full load)	>=7 minutes	>=5 minutes		Depends on the capacity of external battery bank	Depends on the capacity of external battery bank
	Recharge Time	7 hours to 90%			Depends on the capacity of external battery bank	Depends on the capacity of external battery bank
	Charge current(MAX)	2.0A			4.2A or 8A	4.2A or 8A
	Charge voltage	220Vdc ± 1%
Bypass	Automatic Transfer	On overload and UPS failure
	Before UPS Power-on	Default "NO" user adjustable to "YES"
Transfer Time		Zero
Indicators	LED Display	UPS status, I/P & O/P voltage& frequency, Battery voltage, Battery capacity, Loading, Fault code
Audible Alarm		Bypass, On battery mode, Battery low, Overload, Fault
Acoustic noise	At 1 meter distance	<55dB					<60dB
Communications	Intelligent RS232 serial port	Windows 98/NT/2000/XP/2003, Linux, Sun Solaris, IBM Aix, Compaq True64, SGI IRIX, FreeBSD, HP-UX, and MAC
	SNMP (Optional)	Power management from SNMP manager and web browser
	USB (Optional)	Windows family software and Mac OS
Environmental	Operating Temperature	0~40 °C
	Operating Humidity	20~90% ( Non Condensing)
Weight	Net weight (kg)	57	67.5		18	20	27	35	35
UPS Dimension	LWH (mm)	500248616	500248616		500240460	500240460	500248616	500248616	500248616

Plugs

Factory Show

Packaging & Shipping

Packaging Detail: Standard Export carton or wooden package. The Safest Transportation Package

Delivery Detail: 15~20 days for Routine machine, once received deposit, 20~25days for Specified requests, once received deposit. It will be varied according to actual order quantity.

Our Services

1. Respond as Soon as Possible

2. Keep Clients Updated

3. Go the Extra Mile

4. Fix Your Mistakes

5.24 hours online

6. Keep Promises

7. Don’t Confuse Clients with Jargon

8. Be Patient

9. Know Everything we Need to Know

FAQ

Q1. What's the payment term?

A. We accept TT, 30% deposit and 70% balance before shipping and Western Union.

Q2. How's the delivery time ?

A. Usually it will take about 15~20 days for production

Q3. Tell me the standard package?

A. For the small capacity, it uses carton, but for big capacity, we should use strong wooden case for protection.

Q4. What kind of material of transformer?

A.We have two types, one 100% copper and the other is copper with aluminum.It depends on your requirment. In fact, those two have little difference. Copper is better and also price higher.

Q5. Would you accept our logo ?

A.If you have reached the minimum quantity, absolutely no problem to do OEM.

Q6. We want to know your monthly capacity.

A. It varies with product models. For example, monthly capacity can reach near 20000pcs for small capacity and big capacity near 3000pcs.

Q7. Where is your market?

A. Our products are popular in Nigeria, Egypt, Russia, indonesia, Philippines, Italy, America, Pakistan and so on. Hope you can join us and make mutural benifits through our cooperation.

Q8. Does the inverter connect with solar system ?

A. Yes. The unique feature combines inverter, charger and AC auto-transfer switch into one complete system, making the inverter not only connects with solar system, also can be used in office equipment, household items, power tools and etc..
