16x1 lcd display module 1601 Character LCD Display

Product Description

1. Describe :

Manufacturer	YaBin
Series Number	YB1601-A
Display Format	16x1 Dots
Outline Dimension	80(W)x36(H)x12.5(T)mm
Visual Area	64.5×13.8 mm
Active Area	59.45(W)x5.95(H)mm
Character Size	3.20*5.95mm
Diagonal Size	3.0“
Dot (Pixel) Size	0.60X0.70mm
IC Package	COB
IC or Equivalent	SPLC780C or Equivalent
Interface	6800 8-bit/4-bit Parallel
Interface	parallel
Display Type	STN/FSTN
Sunlight Readable	No
Touch Panel Optional	No
Contrast Ratio(Typ)	No
Viewing Direction	6:00
LED Backlight Color	Blue /Yellow Green /Gray
Appearance	White on Blue/Black on Yellow Green/White on Gray
Power Supply(Typ)	5V
Backlight Current (Typ)	15mA
Operating Temp	-20℃~70℃
Storage Temperature	-30℃~80℃
If accept customized	Yes
RoHS Compliance	Yes

2.Overall dimensions:

3.Interface pin connec:

Price

1.Material cost breakdown:
Product model	YB1601-A	specifications	yellow-green / blue 5V (standard configuration)
Items	price (USD)	Items	price (USD)
Print circuit board	0.24	electronic element	0.03
Liquid Crystal Display	0.28	Integrate circuit	0.16
Iron box	0.08	Chip on board assembly (independent production)	0.15
LED backlight (independent production)	0.15	production cost (SMT+COB+assembly+packing)	0.15
Conductive article	0.04	material loss	0.12
cost of total amoun			1.4
2.Market pricing:
Minimum quantity (PCS)	Rate of profit (%)	total profit (USD)	EXW price (USD)
1-49(sample)	35%	0.49	1.89
50-99(Small batch)	30%	0.42	1.82
100-499(Small batch)	25%	0.35	1.75
500-999(big batch)	20%	0.28	1.68
more than 1000(big batch)	15%	0.21	1.61
Special configuration, the price is negotiable. If there is disagreement on the above price please contact me with details, thank you!
