Single arm LED solar street light 3m/4m/5m/6m/7m/8m/10m/12m

height

5m/6m/8m/9m/10m/12m/15m

Hot-dipped galvanized pole with plastic powder coating

Light source

High bright LED

Luminous efficiency :90 lm/w

Illuminance : 10lux-25lux (option)

Color temperature :3500k-6000k (option)

Rated working life : 80000 hrs

Solar panel

Mono-crystalline silicon panel

Power:60w /80w /100w/ 120w/ 150w/ 160w/ 200w/ 240w(option)

High conversion rate: 17%

Weatherproof and vandal resistant

Battery

Deep cycle sealed lead-acid batter with no maintenance .

Lockable enclosure for battery to secure against theft.

Battery position: underground or on the top of pole (option)

controller

12V/5A or 24V/10A (option)

Intelligent charge control to protect from overcharge and over discharge. Lighting time control ensure the lighting from dusk to dawn.

The lamp will be automatically switched by the photocell when detect the darkness

Lighting hours

8 hours / 10 hours/ 12 hours (option)

Rainy days

3 days/ 4 days/ 5 days/ 7 days / more (option)

packing

The poles are wrapped with the nylon strip.

The solar and battery modules are packed in the normal carton box , for the size. Please contact me freely.

installation

Simple and rapidly to install with our plug and play service

Delivery time

Two weeks if order is less than 400 sets

certification

ISO9001 , CE, ROHS , and so on

Power

AC85-260V/50-60HZ

Light source

LED 60W/80W/100W/120W/180W

LED Tj junction temperature

<60°C

LED Efficiency

>100lm /W

Initial luminous flux

6000lm/8000lm/10000lm/12000lm/16000lm/18000lm

Fixture efficiency

>88%

Color temperature

5500k (white light)

color rendering

Ra>75%

Lighting standard

City road lighting design standards
