U pipe Tube Solar Collector(WU)

FOB Price

USD $100 - $250 / Set

1 Set(Min.Order)

Product Details

Place of Origin:	Jiangsu, China	Brand Name:	WKSOLAR	Model Number:	WU
Type:	Pressurized	Application:	Water Heater	Pipe Material:	Copper

U pipe Tube Solar Collector(WU)

Operation:

1. U pipe solar collector composes of metal U pipe , metal slice, insulation layer, vacuum tub and collector frame .

2. water circulates due to water teperature difference between the two sides of U pipe.

3. Solar collector is separated with tank by transmitter inside U pipe

4. Solar radiation converted into heat energy in the water tank by heat exchanger.

Production Model	WU-58*1800	WU-58*1800
Numbers of tube(pcs)	12	15
Absorber area approx(m2)	0.96	1.2
Gross size(m)	20001000130	20001240130
Work pressure	6-8bar
Test pressure	8bar
Heat transfer fluid	Anti-freeze Fluid(Water-Glycol)
ing temperature(°C)	220
Medium	Pure water
Start-up Temperature of heat pipe	≤30°C
Warranty	5years

Material Detail

Production Model	WU-58*1800
Manifold material and thickness	Aluminum alloy,thickness 2.0mm
Header pipe material and thickness	Diameter:32mm,thickness 1.0mm copper pipe
Heat pipe material and thickness	Diameter:14mm,thickness 0.5mm copper pipe
Inslation	Rock wool
Frame material and thickness	Aluminum alloy,thickness 2.0mm
collector mounting	flat roof/slope roof
Inlet and Outlet	1/2" OR 3/4"
Hail resistance	25mm
Coating of vacuum tube and size	SS-C/CU 471500/581800
Flow type	Heat pipe

Wuxi Wankang Solar Water Heater Co., Ltd.: Contact nameLily Wang; Phone86-510-86650098; AddressNo. 6, Xiaohu Road, Huangtu, Jiangyin
