PCB Insulations Tape And DUPONT Tape Film Die Cutter Machine
Technical Data:
Model |
320BII |
420BII |
Max Feeding Width ( mm ) |
320 |
420 |
Cutting Area ( mm ) |
300*300 |
400*400 |
Cutting Speed ( T/M) |
30-170 |
30-170 |
Position Accuracy ( mm ) |
±0.10 |
±0.10 |
Power of Main Engine ( kw ) |
2.2 |
3 |
Size ( mm ) |
2300*1250*1500 |
2550*1450*1650 |
Voltage (V ) |
380 |
380 |
Functional characteristics:
This machine is suitable for multi strips laminating, partial laminating, multi-strip tape sticking, etc.
Imported motor is used for the receiving ( separating ) bottom sheet of adhesive film.
Feeding-Laminating( Multi strips laminating or partial laminating are workable) -die cutting- drain wastage- slitting or rolling, all of them are completed by the computer at the same time.
Scope applicable:
Various insulating materials such as electronic shield materials, PVC, film, Mylar, cooper foil, aluminum foil, foam, etc.
Extra function: Punch:
After attach with the punch equipment, the machine can be used for punch the wastage automatically.
Extra spare part: Sensor.
With this part, the machine can be used for die cut printed material.
Work shop:
We have a big work shop, most of the spart parts of the die cutting machines are produced by ourselves. Here are some pictures of our workshop.
die cutting the tapes:
