Help CenterXT-SMS 150-1300 Mid Speed Vertical Masking Tape Slitting Machine
Related Products
-
XT-SMS 150-1300 Mid Speed Bopp Adhesive Tape Slitting MachineNegotiableMOQ: 1 Set -
XT-SMS300 High Speed Bopp Gum Tape Slitting MachineNegotiableMOQ: 1 Set
-
Vertical Slitting Machine Knife Of XinTaiNegotiableMOQ: 1 Set
-
Vertical High Speed Slitting Machine LineNegotiableMOQ: 1 Set
-
Vertical Jumbo Paper Roll Slitting Machine Of XinTaiNegotiableMOQ: 1 Set
Specifications
mid speed masking tape slitting machine:1 Material: BOPP, PET, CPP, CPE, PVC, paper.
2 Cut material according to your needs
mid speed vertical masking tape slitting machine
paper & plastic slitting machine paper & plastic slitting machine paper & plastic slitting machine paper & plastic slitting machine paper & plastic slitting machine paper & plastic slitting machine
Features
1. A kind of vertical slitting & rewinding machine
2. Independent master control panel, more flexible and even easier operation.
4 Automatic EPC for unwinding, photocell is suitable for tracking the edge and color of transparent material.
5. standard shaft for unwinding, automatic tension controller and magnetic powder brake for unwinding tension control
6. Double cam shaft for rewinding, Magnetic clutch control for rewinding tension control
7. Main motor with frequency converter for speed regulation
8. Equipped with rim charge conveying device.
9. Automatic meter counting device
high speed slliting machin
Printing Materials
Suitable for PE,PP,PET,OPP,PVC and low gsm paper etc.
Max width |
1300mm |
Max unwinding diameter |
600mm |
Max rewinding diameter |
400mm |
Slitting Specificaiton |
30-1200mm |
Slitting speed |
5-160m/min |
Precision of edge correction |
‹0.5mm |
Weight |
1800kg |
Dimension LxWxH |
2500x1100x1400 |
NOTES: Changes Can be Made Based on Your Requirements!
Our Services
1 One year quality warranty.
2 Engineers are available overseas.
3 Good after-sale services.
