Specifications
paper roll central surface coiling slitter Spec:1 Load/unload way: Air shaft
2 Edge correction: Automatical
paper roll plastic roll central surface coiling slitter
high speed slliting machine
Slitting Materials
Material: PE,PP,PET,OPP,PVC and low gsm paper etc
Unwinding Unit
1. Unwinding tension control: 5kg magnetic powder brakes
2. Load/unload way: Air shaft
3. Edge correction: Automatical
Rewinding unit
1. Rewinding tension control: 5kg magnetic powder clutch (2 set)
2. Tension display: eter display
3. Load/unload way: Central surface coiling Air shaft
4. Electromagnetism speed control
Slitting unit
1. Blade: one set circular blade ( five circular blades).
2. Blade control way: Manual
Main driver
1. Structure: Steel and soft roller
2. Driving method: Frequency Motor traction
3. Chain synchronism
4. Convey roller: Aluminium guide roller
Other unit
1. Waste material blowing device
2. Working prevention device
Main Parameter
Max width |
1300mm |
Max unwinding diameter |
700mm |
Max rewinding diameter |
400mm |
Paper core diameter |
φ76mmφ152mm |
Slitting speed |
‹180m/min |
Precision of edge correction |
‹0.5mm |
Tension setting range |
0-80N.m |
Main power |
4.5kw |
Weight |
About 2000kg |
Dimension (LxWxH) |
2100*2000*1500mm |
NOTES: Changes Can be Made Based on Your Requirements!
Our Services
1 One year quality warranty.
2 Engineers are available overseas.
3 Good after-sale services.
