Help CenterSWDL150 Spiral Piling Machine for Construction Project
Related Products
-
SWDL150 Pile Driver for Construction ProjectUS$ 10,000 - 60,000MOQ: 1 Piece -
SWDL150 Pile Driver for Drive I Beam Pile, Soil Area, Mine Etc.US$ 10,000 - 60,000MOQ: 1 Piece
-
SWDL 150 Ground Screw Spiral Piling MachineUS$ 47,000 - 50,000MOQ: 1 Piece
-
Spiral Piling Machine for Ground Screw and Solar MonuntingUS$ 40,000 - 46,000MOQ: 1 Set
-
WBQ HD-05 Ground Screw Electric Driver for Construction, Solar Power System Etc.US$ 3,000 - 4,000MOQ: 1 Piece
Specifications
The spiral piling machine is base on the excavator system, which can complete digging and drilling work by different work deviceThe spiral piling machine is base on the excavator system, which can complete digging and drilling work by different work device.
Easy and flexible operation: all actions including travel, dozer, turntable swing, work devices, pile rotation and feed etc. are all controlled by advanced hydraulic pilot valve. Work operation is in the cabin which can reduce operating force and operator's load and advance the control stability.
1. Drill frame angle display is fit in the cab, which make operation clearly.
2. The machine is supplying special clamping fixtures for piles, easy assembling and disassembling, high efficiency.
3. The machine is supplying pile guiding device which can ensure the verticality of pile drill.
4. Safety and reliable key parts: YANMAR-3TNV82A engine from Japan, hydraulic system main pump, main valve, swing motor, travel motor are all from KYB Janpa.
Technical Data:
Pile Drilling Parameter | ||
|
Drilling Diameter |
mm |
76 |
|
Drilling Depth |
mm |
1800 |
Chassis | ||
|
Wheel gauge |
mm |
1430 |
Track gauge |
mm |
1150 |
Crawler width |
mm |
250 |
Grounding clearance |
mm |
280 |
Dozer length |
mm |
1400 |
Travel Capacity | ||
Max. Traction |
KN |
19 |
|
(Max/Min) Travel speed |
Km/h |
4.7/2.6 |
Climbing capacity |
° |
20 |
Feed | ||
Length of feeding beam |
mm |
3400 |
Stroke |
mm |
2000 |
Speed |
m/min |
2 |
Rotation | ||
Torque |
N.m |
1500 |
Speed |
rpm |
50 |
Engine | ||
Model |
|
YANMAR-3TNV82A |
Displacement |
L |
1.331 |
Power/Rev. |
kw/rpm |
16/2200 |
Fuel tank volume |
L |
42.5 |
Turntable Swing |
° |
360 |
Dimension(L*W*H) |
mm |
5500X1400X3000 |
Machine Weight |
kg |
3000 |
