F88.9*1200*220 Ground Screw Anchor With Flange for Solar Mounting
- TIAN JIN
- T/T D/P D/A Credit Card
You May Like
-
Ground Screw Anchor With Flange for Solar Mounting (Factoty With ISO Certificate)
-
F114*2000*220 Hot Dipped Galvanzied Ground Anchor With Flange
-
Hot Dipped Galvanized Ground Screw Anchor for Building Foundation
-
F219*2700*298 Galvanized Ground Screw Anchor
-
Galvanized Solar Ground Screw Anchor F219*3500*298
-
U Tpye Galvanized Ground Plug
Product Details
| Place of Origin | Hebei, China | Brand Name | WBQ | |
| Model Number | WBQ F88.9*1200*220 | Type | Pole Anchor | |
| Material | Steel | Diameter | 88.9 MM | |
| Length | 1200 MM | Capacity | 18 KN |
Product Description
A. Details of WBQ Ground Screws Anchor:
| Details of WBQ Ground Screws Anchor (WBQ F88.9*1200): | |
| 1. Outer dia: | 88.9mm |
| 2. Length: | 1200mm |
| 3. Innerθ: | 81.7mm |
| 4. Adjustmentθ: | M24 |
| 5. Durchmesser Lochbohrung: | 6×θ14 |
| 6. Throatθ: | 167mm |
| 7. Flange Thickness: | 8mm |
| 8. Flange outerθ: | 220mm |
| 9. Material: | ISO630 Fe A / DIN EN10025 Fe 360 B |
| 10. Tube thickness: | 3mm-4mm |
| 11. Surface finish: | Hot Dip galvanize to DIN EN ISO 1461-1999 |
| 12. Packing: | steel pallet and stretch film |
| 13. Applications: | Solar Mounting Rack System, Fence, Sheds and Containers, Boards and Banners, Flag Poles and Marks |
| 14. Soil conditions: | Clayed Ground, Desert, Gobi Desert |
| 15. Drawing force: | 10 KN |
| 16.Loading power: | 18 KN |
| 17.Horizontal torque force: | 4.2 KN |
B. Advantages of WBQ Ground Screws Anchor:
- High compressive loads, extraction load and lateral pressure loads, with verification in structural calculations
- No digging and no concrete
- Environmentally friendly due to minimum surface sealing
- No damage to the surrounding area
- No negative impact on the landscape
- No waiting times: can be subjected to loads immediately!
- High installation capacities with special-purpose machinery for Foundation Construction
- Special foundations for extra-deep Foundation requirements
- Fast and inexpensive to dismantle and relocate, with the site being left in its original state
- No costs for disposing of Foundations which have become unusable
- Long lifetime
C. Applications of WBQ ground screws anchor:
1. Timber Construction | 2. Solar Power Systems |
3. City and Parks | 4. Fencing Systems |
5. Road and Traffic | 6. Sheds and Containers |
7. Flag Poles and Marks | 8. Garden and Leisure |
9. Boards and Banners | 10. Event Structures |
