8 inch all in one pc touchscreen with Intel Atom D2550 1.86GHz 2g ram 32g ssd
| Configuration | |
| Model | IN-8D42 |
| CPU | Intel Atom D2550 1.86Ghz |
| Network | INTEL 1000M *2 |
| RAM | Support NB Memory SO-DIMM DDR3 (Maximum to 4G RAM) |
| Storage | Support 1*Mini PCIE Msata SSD (SSD Max.512G) |
| Wi-Fi | Wireless-(150Mbps or 300Mbps optional) |
| Package | AIO+Power Supply+Power Cord (USA, European, UK Types for optional)+Stand |
Rear I/O:
4*USB
2*LAN
VGA
HDMI
Audio input and output
1*RS232+2 RS232 (Or adjustable to RS485/RS422)
With Fan
2G RAM,32G SSD
Features:
8 inch tablet computer touch all in one, industry 3COM dual Ethernet ports, and high stability
8-inch industrial touch all in one pc, the whole lightweight, aluminum panels, precision machining, resolution 800 * 600, 7 * 24 hours of steady work, similar products but with the highest quality and cost-effective, welcomed the purchase
Aluminum structure, precision machining, machine compact and lightweight, 5mm thin panel design, suitable for embedded installation
Original 8-inch LED LCD screen, operating temperature -10 ~ 50 , with a resolution of 800 * 600
Make up the difference SSD or HDD, can be replaced with a larger capacity SSD or laptop hard drive
Detailed parameters
Dimensions:218mm * 176mm * 50mm
Hole Size:207mm * 165mm
Display:8-inch LED screen resolution of 800 * 600
Touch screen:Industrial 4-wire resistive screen
CPU:ATOM D2550 Dual Core 1.86G
RAM: Optional
Hard disk:Optional
NIC:1000M (Note: The default is single card, dual card version plus $20, $10 for 300M wireless)
Built-in speakers:No
Back of the interface:RS232 * 2
The lower side of the interface:DC_IN * 1, LAN * 2, USB * 4, VGA * 1, HDMI * 1, AUDIO * 2, RS232 * 1
Gross weight:1.8KG
Package Contents:All in one pc, 12V 4A power supply, power line, flush mount snap 4
Features:12V DC input Power consumption 20W, support calls boot, wake on LANMachine pre-installed WINDOWS, good stability, can be switched to work long hours
Note: This machine WINXP system graphics driver does not support 3D hardware acceleration, you can not run 3D applications, if there is need, you must use WIN7 system.
1. Using Intel® ATOM D2550 1.86G dual-core low-power processor
2. High quality 800 * 600 resolution with 8 Inch LED screen, resistive touch screen with high sensitivity, high accuracy, click long life.
3. All-aluminum construction, durable, anti-vibration, shock, small fine
4. Standard VESA screw holes, you can choose to install a flexible form
Specifications
Size 8 inch display
LED industrial displaysResolution of 800 × 600Brightness 200cd / m2Contrast Ratio 500: 15ms response time
Physical characteristics of the machine Dimensions 218 mm (length) × 176 mm (width) × 50 mm (H)Hole size 207 mm (length) × 165 mm (W)
Material sheet metal / aluminum alloy
Weight 1.1KG /1.8KG (Net / Gross)
Color Black
Touch the touch screen feature high-quality 4-wire resistive touch screen
Click to life> 200 million times
Performance Configuration C P U ATOM D2550 Dual Core 1.86G
Graphics card INTEL GMA3600
Support system Windows XP, Windows 7, LINUX
I / O interfaces U S B 4 x USB 2.0A serial RS232 interface (on the back of increase two RS232)(Adjustable for the RS485 / RS422)Ethernet port: 2 INTEL dual 1000M wired LAN
Optional 2W speaker audio
Display VGA * 1, HDMI * 1
Environmental testing IP protection class IP65 default
Operating temperature -10 ~ 60 surface air flowStorage temperature -20 ~ 70 Humidity 10% ~ 95% @ 40 non-condensing
Packing list:All in one PC 1Power Adapter 1Power line 1Flush mounting clips 4
