Specifications
1.Fully Automated Medical FIA Analyzer2.Stable function and flexible disign
3.Provide OEM service
4.High throughput
Fully Automated Medical FIA Analyzer
ADDCARE automatic FIA workstations are the reliable tools for the broadest range of routine assays in Life Sciences and Diagnostic. We also provide the flexibility for customization in OEM solutions.
Workflow of the instrument including featuring barcode reading, preparing the samples according to a work list, washing the plates and complete all necessary preparation work, and then take the plate to the ELISA reader, at last, print the test report.
STANDARD CONFIGURATION
Specifications |
ADC FIA 600 |
|
Pipetting Spec |
Continuous load sample, parallel serial pipetting |
|
Sample and reagent pipetting Probe |
8pc |
|
Tip type |
Disposable plastic tips, non conductive, low cost Liquid level, clot, empty tube detection function |
|
Sample-tip range |
Tip type 300µL,800µL optional |
|
Tips rack capacity |
384tips(4positions, each can hold 96tips) |
|
Replicates |
Up to 288 samples, standards and controls |
|
Accuracy |
≤2.0%( 100µl) |
|
Precision |
≤0.75%( 100µl) |
|
Reagent fluid capacity |
Standard:32reagent tanks position |
|
Intelligent transfer arm |
1pc, grab the plate tightly, avoid dropping |
|
Automatic barcode scanner |
1pc |
|
Incubator Spec |
||
Incubation plates |
16pcs, each plate up to 12 assays |
|
Temperature range |
Ambient +5 oC--60 oC uniformity ±0.5oC |
|
Shaking, temperature control |
Independent , parameters can be set |
|
Washer Spec |
|
|
Manifold configuration |
96-pin washer, 3 plate positions |
|
Dispense-volume range |
50-1000µl, residual volume<2µL |
|
Cross washing function |
Yes, liquid inject height, soak time etc multi-parameter programmable |
|
Wash buffer capacity |
3pc Low-buffer alarm function |
|
Reader Spec |
|
|
HIS/LIS, CE certificate, ISO9001,ISO13485, Completely intellectual property rights | ||
Certification
Welcome to visit our factory and find more you like.
