MINI EXCAVATOR LOADER /4WD4WS , SMALL BACKHOE LOADER
MINI EXCAVATOR LOADER / 4WD4WS BACKHOE / SMALL BACKHOE LOADER
| Loading bucket capacity | 1.0 m³ | |
| Backhoe bucket capacity | 0.3 m³ | |
| Max digging force | ≥44.4KN | |
| Max breakout force | ≥53.5KN | |
| Max tractive force | ≥60KN | |
| Level passing radius | 5225mm | |
| Engine | ||
| Model | CUMMINS 4BT3.9 | |
| Rated power | 60KW | |
| Rated speed | 2200rpm | |
| Fuel consumption ration | ≤240g/Kw.h | |
| Transmission system | ||
| Torque converter type | Single plase, single stage,3 elements | |
| Torque ratio | 3.7 | |
| Transmission type | Fixed shaft power shift | |
| Gear shift | 2 forward shift,2 reverse shift | |
| Type | 4-wheel drive | |
| Steering system | ||
| Type | Articulated load sensing hydraulic steering system | |
| Steering angle | 35°each side | |
| Main transmission type | Spiral gear, first stage decelerate | |
| Final decelerate type | First stage, planetary gear decelerate | |
| Tyre | ||
| Specification | 16/70-20 | |
| Front tyre pressure | 0.23-0.25Mpa | |
| Rear tyre pressure | 0.23-0.25Mpa | |
| Working system | ||
| System working pressure | 17.5Mpa | |
| Digging equipment | Type | Backhoe |
| Max digging radius | 5670mm | |
| Loading equipment | Type | Eight-connecting pole |
| Dumping height | 2700mm | |
| Dumping distance | 860mm | |
| Brake system | ||
| Service brake | Air over hydraulic disc brake on 4 wheels | |
| Parking brake | Manual internal expansion brake | |
MINI EXCAVATOR LOADER /4WD4WS , SMALL BACKHOE LOADER
SDLG B877 is a middle-size multi-function engineering machine newly designed with high cost performance and is widely used in various building construction engineering, such as road construction and caring, cable lying, electricity and airport engineering, municipal construction and quarrying work, in city and countryside.
Linyi Vision Construction Machinery Co., Ltd has been offering a complete range of most reliable and cost-effective construction equipments from China to rest of the world which include but not limited to wheel loader, backhoe loader, motor grader, road roller, excavator, truck crane, bulldozer, and etc.
As one of the biggest export distributors of SDLG, XCMG and Shantui products, our business has reached more than 60 regions or countries world widely.
Besides, we are also supplying genuine parts. The 200 warehouse and convenient transportation will guarantee you the high availability and short lead time.
Each of our team is rich in construction machinery background and committed to create the most values to our customers.
