Home > Packaging & Printing > Printing Machinery > Screen Printer > YT 4060 Semi Automatic Vertical Screen Printing Machine Such as Membrane Switch Circuit Board
YT 4060 Semi Automatic Vertical Screen Printing Machine Such as Membrane Switch Circuit Board
US$ 5,500 - 5,600
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
YuTai, YuTai
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
YT 6090 Semi Automatic High Precision Screen Printing Machine For Glass Decal PaperUS$ 6,500 - 6,600MOQ: 1 Set -
YT 6090 Semi Automatic Vertical Flat Screen Printing Machine For Ceramic Decal PaperUS$ 6,500 - 6,600MOQ: 1 Set
-
YT 8012 Wedding Card Tile Printer Tilt Semi-automatic Powder Spray MachineUS$ 6,500 - 6,600MOQ: 1 Set
-
YT 6090 Ceramics Printer Tilt Semi-automatic Printing MachineUS$ 5,500 - 5,600MOQ: 1 Set
-
YT 1218 High Precision Semi Automatic Silk Screen Printing Machine Switch Circuit BoardUS$ 1 - 2MOQ: 1 Set
Condition
New
Place of Origin
Guangdong, China
Brand Name
YuTai, YuTai
Model Number
YT4060, YT4060
Usage
Card Printer, Label Printer, Paper Printer, Paper Printer
Automatic Grade
Other, Automatic, Automatic
Voltage
220v
Gross Power
3kw
Dimensions(L*W*H)
700*900
Weight
450kg
Certification
SGS
Warranty
1year
After-sales Service Provided
Engineers available to service machinery overseas
YT 4060 Semi Automatic Vertical Screen Printing Machine such as membrane switch circuit board
| Name | YT 4060 Semi Automatic Vertical Screen Printing Machine such as membrane switch circuit board | ||||
| Item NO. | YT-4060 | ||||
| YT-6090 | |||||
| YT-80120 | |||||
| YT-1218 | |||||
| TYPE | YT-high precision vertical flat screen printing machine | ||||
| Model | YT-4060 | YT-6090 | YT-80120 | YT1218 | |
| Max.printing size (mm) | 400*600mm | 600 x 900 mm | 800 x 1200mm | 1200*1800mm | |
| Max.size of frame (mm) | 700*900mm | 800*1100mm | 1000*1400mm | 1400*2000mm | |
| Main parameter | Max.print speed (p/h) | 1100 | 1100 | 1100 | 1100 |
| Total power (KW) | 3 | 4 | 4 | 4 | |
| Working air pressure | 0.5-0.8mpa | 0.5-0.8mpa | 0.5-0.8mpa | 0.6-0.9mpa | |
| Voltage | 380V/220v | 380V/220v | 380V/220v | ||
| Weight (KG) | 450 | 580 | 680 | 800 | |
| Packing | World export standard wooden case | ||||
| MOQ | 1 set | ||||
| Delivery time | Within one month after receiving the deposit | ||||
| Note | This printing machine have 4 sizes | ||||
Product Characteristic
1.Screen plate can lift and decline by electromotion;printing ink flows without any deflection,
2.Control by micro-computer,lift and lower are controlled by Adderley transducer as well as the printing,
3.Adopts imported guide rail, SMC cylinder and pneumatic Organ,quality assurance,
4.Plywood contrils by automatic eqipment and it make sure the ply-wood immovable,
5.It is suitable for various printing, such as membrane switch circuit board,ceramic decal,metal glass all flat sheet materials.
Welcome to visit and inquiry.
Not only business between you & us, but also friend making.
Good luck and Happy bidding!
