professional ss wire mesh dust cyclone separator

Specifications

professional ss wire mesh dust cyclone separator
1.ISO 9001-2000
2.OEM service
3.SS material
4. Manufacturer

professional ss wire mesh dust cyclone separator

Advantages:

1.) 27 years professional

2.) Stable and constant pressure

3.)  High filtration efficiency

4.)  Exquisite Craftsmanship

5.) High dust holding capacity

6.) Special design team

professional ss wire mesh dust cyclone separator

Product Overview:

1.)As air oil separator filter in rotary air compressor and vacuum pump, due to the compressed air separation, condenses oil vapor.



2.)YQLX series filter adopts high superfine fiber agglomerate anti-corrosion materials as filtration, advance by filter layer, superfine fiber layer, support layer and layer and layer, etc, to ensure settlement of large oil can be separated directly, tiny oil gas dissolved in through the filter was disintegrated into the oil droplets greatly condenses and exclusion.



3.)With high efficiency filtration separation (after no more than oil gas 3mg/m3), the initial pressure is low long using life etc.

professional ss wire mesh dust cyclone separator

Model:

Model	flowing(m3/min)	Residual oil(mg/m3)	initial pressure differential(MPa)	Working pressure(MPa)	Working temperature(°C)	Size (mm)				MANN Corresponding model
						D	D1	D2	L
YQLX I-2	2	3	0.02	0.7	120	φ170	φ88	φ135	200	49 000 50 531
YQLX I-3.5	3.5					φ170	φ88	φ135	305	49 000 50 411
YQLX I-3.5	3.5					φ200	φ123	φ170	230	49 000 50 201
YQLX I-4.5	4.5					φ200	φ123	φ170	305	49 000 50 121
YQLX I-6.5	6.5					φ200	φ123	φ170	435	49 000 50 111
YQLX I-8	8					φ328	φ220	φ272	305	49 000 50 101
YQLX I-9	9					φ274	φ165	φ220	435	49 000 50 171
YQLX I-12	12					φ328	φ220	φ275	450	49 000 50 321
YQLX I-12	12					φ274	φ165	φ220	600	49 000 50 131
YQLX I-14	14					φ355	φ245	φ300	500	49 000 50 191
YQLX I-17	17					φ355	φ245	φ300	600	49 000 50 181
YQLX I-19	19					φ355	φ245	φ300	660	49 000 50 221
YQLX I-20	20					φ324	φ220	φ275	750	49 000 50 521
YQLX I-24	24					φ355	φ245	φ300	820	49 000 50 481
YQLX I-29	29					φ355	φ245	φ300	1000	49 000 50 541
YQLX I-42	42					φ570	φ400	φ475	900	49 000 50 581



professional ss wire mesh dust cyclone separator

Our Company:

1.) Xinxiang D.King Industry Co., LTDhas won the great fame by its clients with the excellent design and advanced technology of transfer carts, besides that, it is also believed to be the long cooperate partners by its customers with the perfect after-sale service.



2.)  Xinxiang D.King Industry Co., LTD  have a good reputation among our customers. “United and progress” is our spirit and "good faith" is our management tenet. Thank you for choosing our high quality products and good services.

professional ss wire mesh dust cyclone separator

Market:
