manufacture series industrial equipment parts air purifier filter

Specifications

air purifier filter
1. ISO 9001:2000 approved
2. High efficiency
3. Long service life

manufacture series industrial equipment parts  air purifier filter



Introductions: KLX series air filter applicable to air separation, purification of dust, In order to ensure cleanliness requirements system, extending use life.

This filter to kapok fiber or polyester fiber filters material, to fold into corrugated shape, and within the time frame.

Characteristics: With high efficiency, low resistance, good permeability. High reliability, long life and other characteristics, polyester fiber materials have more resistance, corrosion resistance, water, not easy clean, can use repeatedly pulse.

Use cope: It is widely used in blast furnace, thus standing raw blower air machine, various raw materials of gas turbine, takes a long time to run the diesel engine, air dust-contained two higher requirements of central air conditioning system, central control and other large unit inlet filtration powder coating system powder recovery system.

Structure:end and bottom caps,material is aluminum , iron, rubber

inner and outer tube, material is galvanized sheet

filter medium ,material is glassfibre , PP non-woven , filter paper

 air purifier filter Model:

Name	Model	Capacity(m3/h)	Pressure (Pa)	Working temperature(°C)	Filtration efficiency(%)	Size (mm)
						D	D1	L
air filter element	KLX-850	850	120-175	Bombax cotton 105 Polyester fiber 135	Bombax cotton 99 Polyester fiber 99.99(more than 2um)	320	212	560
	KLX-900	900				320	212	610
	KLX-1000	1000				320	212	660
	KLX-1050	1050				320	212	700
	KLX-1100	1100				350	240	600
	KLX-1150	1150				350	240	650
	KLX-1200	1200				350	240	710
	KLX-1800	1800				400	291	315
