Home > Products > Expanded Metal Machine > Expanded Plate Mesh Machine From Manufactory
Expanded Plate Mesh Machine From Manufactory
- 20 Piece / Pieces per Month
- Tianjin
- T/T
Product Details
Place of Origin: | Hebei, China | Brand Name: | Feiteng | Model Number: | Expanded Plate Mesh Machine From Manufactory |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Expanded Plate Mesh Machine From ManufactoryApplication:Light industry, electronics, micro batteries, and other fields.
Expanded Plate Mesh Machine From Manufactory
The machine are used for punching shear the cold crimped engine bed with the thickness of 1.2-1.5mm2 the width of 2000mm material strength of 450N/mm,the specifications of punching shear are su~eyed by the bit of TB5-20 mesh grid plate.
Type | FT25-6.3A | FT25-16 | FT25-25 | FT25-63A | FT25-63B | FT25-100 |
Depth(mm) | max.1.0 | max.1.0 | max.1.5 | max.2.5 | max.3 | max.4 |
Punching Width(mm) | 500 | 1000 | 1250 | 2000 | 2000 | 2000 |
Times | 180/min | 150/min | 150/min | 70/min | 45/min | 60/min |
Distance(mm) | 0-1.15 | 0-1.2 | 0-1.2 | 0-4 | 0-4 | 0-4 |
Length of Mesh(mm) | max.20 | max.25 | max.30 | max.100 | max.200 | max.150 |
Motor | 2.2KW | 3KW | 4KW | 11KW | 11KW | 15KW |
Weight | 0.95T | 2T | 3T | 10T | 10T | 12T |
Measurement (mm) | 950 x 570 x1780 | 1800 x 1320 x1550 | 1940 x 1600 x 2010 | 2400 x 3500 x 2300 | 2400 x 3500 x 2300 | 3600 x 2500 x 3000 |
Price(FOB) | USD 8200-35000 | |||||
Supply ability | 20 sets/month |
Our Factory
Huanghua Feiteng Wire Mesh Machine Co.,Ltd
1500 square meters productin space
Welcome to visit our Huanghua office and factory.
Feiteng is located in Huanghua County adjacent to capital city of Beijing,Tianjin International Newport,Shijiazhuang,Hebei Province.
Feiteng is a unique combination of private enterprises,the existing staff more than 50 people,with designers,engineers,senior technical backbone of nearly 10 people,covers an area 1,500 square meters,fixed assets 1,000,000 yuan. We have been manufacturing this product of 16 years,it enables us to accumulate abundant practical welding-tech experiences.
Service:We provide installation personnel to be presen.Our guarantee time is one year.Do you have any problem can contact us.We will provide the best quality after sale service.
