Help CenterMulti-function Embossing Keypad Switch Panel
Related Products
-
Waterproof Switch Cover /panel Mount Numeric KeypadUS$ 0.4 - 0.8MOQ: 500 Pieces -
OEM Tactile Membrane Switch Keypad With 3m Adhesive StickersUS$ 0.4 - 0.8MOQ: 500 Pieces
-
Medical Machinery Membrane/ Embossed Overlays With Clear Window Polycarbonate OverlaysUS$ 0.4 - 0.8MOQ: 500 Pieces
-
Rubber Membrane Keypad Sticker /tactile Waterproof Membrane Switch CoverUS$ 0.4 - 0.8MOQ: 500 Pieces
-
Automotive Instrument Weight/ Measurement Test Equipment Machinery Membrane Control PanelUS$ 0.4 - 0.8MOQ: 500 Pieces
Specifications
membrane switch1 LED lamp
2.embossed or metal dome
3 printed textured coating
4 custom-made
Multi-function Embossing keypad Switch Panel
Performance
Electrical
Operating Voltage: 0~35 V DC.
Operating Current: 100 MA Max.
Operating Contact Resistance: Less than 100 OHMS typical
Contact Bounce: Less than 5 Milliseconds typical.
Conductors: Printed silver conductive inks or carbon blend.
RFI and ESD Shielding: Available in most configurations.
Mechanical
Life Expectancy: 1,000,000 actuations per switch position
Actuation Force: 6~24 ounces (170~680g), Range depending on customer
specification.
Switch Travel: .005" to .030" (0.1~0.8mm) typical.
Overall Thickness: .020" to .050" (0.5~1.3mm) typical.
Environmental
Storage Temperature: -40°C (-40°F) to +70°C (158°F).
Storage Altitude: Sea level to 35,000 feet.
Operating Temperature and Altitude: -30°C (-30°F) to +75°C (170°F).
Send Inquiry to This Supplier
