Protective Steel Nets

Name: Protective Steel Nets
Brand: Konson
SKU: 117736729
Availability: InStock

US$ 1.8 - 2 MOQ: 5000 Square Meters

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Konson

Model Number:

KS-GH

Konson Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Konson

Model Number KS-GH

Material Other, Galvanized;PVC/PE coated;Galfan coated, Galvanized Iron Wire

Type Other, Hexagonal wire netting

Application Gabions

Hole Shape Hexagonal

Aperture 60*80;80*100;100*120;120*150

Wire Gauge 2.0-4.0

Specifications

protective steel nets
1 CE,SGStest
2 Various size
3 Professional manufacturer
4 Comptitive price

protective steel nets

is manufactured by PVC coating Line.

Firstly,coating polyvinyl chloride on mesh wire and straighten the wire.

Secondly,pvc coated gabion is made by gabion machine.

Wire diameter varies with the hexagonal nettings.

For hexagonal wire netting with no pvc coating, the wire diameter ranges from 2.0mm to 4.0mm.

For those PVC coated hexagonal wire netting,the outside diameter ranges from 3.0mm to 4.0mm.

The wire of the outside frame edge is one wire gauge thicker than the wire used for hexagonal wire netting.

specification

Opening(mm)	Wire diameter (mm)	Wire Diameter (PVC Coated)/ Inner/Outside(mm)	Size(m)
60x80	2.0-2.8	2.0/3.0-2.5/3.5	1x1x0.3 1x1x0.5 2x1x0.3 2x1x0.5 2x1x1 4x2x1 6x2x0.3 6x2x1 As your request
80x100	2.0-3.2	2.0/3.0-2.8/3.8
80x120	2.0-3.2	2.0/3.0-2.8/3.8
100x120	2.0-3.4	2.0/3.0-2.8/3.8
100x150	2.0-3.4	2.0/3.0-2.8/3.8
120x150	2.0-4.0	2.0/3.0-3.0/4.0

PVC Coated Hexagonal Wire Netting
mesh			Min. Gal.v. G/SQ.M	Width	Wire Gauge (Diameter) BWG
Inch	mm	Tolerance(mm)	Min. Gal.v. G/SQ.M	Width	Wire Gauge (Diameter) BWG
3/8"	10mm	±1.0	0.7mm - 145	2' - 1M	27, 26, 25, 24, 23
1/2"	13mm	±1.5	0.7mm - 95	2' - 2M	25, 24, 23, 22, 21
5/8"	16mm	±2.0	0.7mm - 70	2' - 2M	27, 26, 25, 24, 23, 22
3/4"	20mm	±3.0	0.7mm - 55	2' - 2M	25, 24, 23, 22, 21, 20, 19
1"	25mm	±3.0	0.9mm - 55	1' - 2M	25, 24, 23, 22, 21, 20, 19, 18
1-1/4"	31mm	±4.0	0.9mm - 40	1' - 2M	23, 22, 21, 20, 19, 18
1-1/2"	40mm	±5.0	1.0mm - 45	1' - 2M	23, 22, 21, 20, 19, 18
2"	50mm	±6.0	1.2mm - 40	1' - 2M	23, 22, 21, 20, 19, 18
2-1/2"	65mm	±7.0	1.0mm - 30	1' - 2M	21, 20, 19, 18
3"	75mm	±8.0	1.4mm - 30	2' - 2M	20, 19, 18, 17
4"	100mm	±8.0	1.6mm - 30	2' - 2M	19, 18, 17, 16
