Gabion Wire Mesh Fill the Stone

Gabion Wire Mesh Fill the Stone photo-1
US$ 1.5 - 4.5 MOQ: 800 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Konson
Model Number:
KS-G
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name Konson
Model Number KS-G
Material Other, Galvanized Iron Wire, Galvanized Iron Wire
Type Other, twist hexagonal wire mesh
Application Gabions
Hole Shape Hexagonal
Aperture 50*70,60*80,80*100,80*120,100*120,100*150,120*150mm
Wire Gauge 2.0-4.0mm

Specifications

gabion wire mesh fill the stone
1.Galvanized,Galfan,PVC
2.Mesh:60x80,80x100,100x120mm
3.High quality&service
4.Fast delivery

gabion wire mesh fill the stone
We can also call it Galvanized Gabion.

It is used world wide for retaining wall, slope stabilization, channel lining, rockfall protection and many other applications for over 100 years.



Hexagonal Wire Netting/ Hexagonal Wire Mesh/ Gabion Boxes/ Gabion Baskets/ Stone Cages

Aplications:
Protecting them from being washed away
Preventing of rock breaking
Bridge protection Water and soil protection
Bridge protection
Strengthening structure of soil
Retaining wall.

Specifications of galvanized hexagonal wire mesh.


Opening(mm)

Wire diameter (mm)

Wire Diameter (PVC Coated)

/Inner/Outside(mm)

Size(m)

60x80

2.0-2.8

2.0/3.0-2.5/3.5

1x1x0.3  1x1x0.5
2x1x0.3  2x1x0.5
2x1x1    4x2x1
6x2x0.3  6x2x1
As your request

80x100

2.0-3.2

2.0/3.0-2.8/3.8

80x120

2.0-3.2

2.0/3.0-2.8/3.8

100x120

2.0-3.4

2.0/3.0-2.8/3.8

100x150

2.0-3.4

2.0/3.0-2.8/3.8

120x150

2.0-4.0

2.0/3.0-3.0/4.0

Details:

1.Standard:ASTMA75-97,BS1052,EN-10223-3,YB/T4190-2009,ISO9001:2000,CE

2.Materials: Hot dip galvanized wire

            Heavy zinc-coated wire(220-290g/m2 )

            PVC coated wire,polyethylene coated wire

            Galfan wire

3.Coating: Zinc,PE,PVC,Zn-5-AL,Zn-10-Al

4.Gabion selvedge wire diameter: 2.2mm,2.4mm,2.7mm,3mm,3.4mm,4mm

5.Gabion tie wire/lacing wire diameter: 2.2mm, 3%,5%,8% of weight.



Supply 8,000sqm one day.
gabion wire mesh fill the stone
