70" Outdoor High Brightness Waterproof Advertising Monitor

Name: 70" Outdoor High Brightness Waterproof Advertising Monitor
Brand: Taiyun, Taiyun
SKU: 117733387
Availability: InStock

US$ 18,085 - 27,128 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Taiyun, Taiyun

Model Number:

TY-KA184

Guangzhou Taiyun Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Taiyun, Taiyun

Model Number TY-KA184

Type TFT

Application Outdoor

Panel Size 1549.44*871.56mm, 70 inch, From 42 inch to 70 inch

Max Resolution 1920x1080p, 1920 x 1080

Viewing Angle H178/V178

Pixel Pitch 0.744mm

Color 16.7M, 16.7M, Silver,Break,Gold (accept color customized )

Contrast Ratio 5000:1

Brightness 2000 nits, 2000 nits

Response Time 6ms

Input Voltage 90-260v

70" Outdoor High Brightness Waterproof Advertising Monitor

Introduction

Waterproof and dust-proof meet IP 65 protection grade,unique full-sealed for outdoor use;
1500~3000nits, samsung panel;
Sunlight readable outdoor LCD;
Air condition cooling system, Work stably and effeciently in wide temperature range(-40°c~+55°c);
Light sensor system, LCD will adjust the light Via environment light, and anti-glare in dark;
Touch screen optional, IR touch function;
PC media player-All-in-One PC;
No black screen under +55°C highest temperature;
Anti- corrosion 8 years, Anti-Rust, Anti-Graffiti, Anti-Vandal, Anti-theft, Anti-salt mist;
19-82inch free standing/ wall mounted outdoor lcd;
OEM&ODM service.

Application

Commercial Organizations:Supermarket, Shopping mall, Exclusive agency, Chain shops, Department Stores, Hotel, Restaurants, Travel agency, Pharmacy, Convenient stores, Group Headquarter, etc;
Financial Organizations:Banks, Negotiable Securities, Funds, Insurance company, Pawnshops, etc;
Non-profit Organizations:Telecommunication, Post offices, Hospital, School, etc;
Public Places:Subway; Airport, Railway station, Bus station, Gas station, Toll stations, Bookstore, Parks, Exhibition Hall, Stadium, Museums, Convention centers, Ticket offices, Job center, Lottery center, etc
Real Estate Property:Apartments, Villas, Office, Commercial Buildings, Model rooms Property Brokers, etc;
Entertainment:Theatre, Fitness Hall, Country Club, Massage Shop, Bars, Cafes, Internet Bars, Beauty shop, Golf course center, etc.

Standard Configuration

Display	Panel Size	70"
	Aspect Ratio	16:9 Portrait
	Resolution	1920*1080 (Full HD)
	Brightness	2000 cd/m²
	Contrast Ratio	3000:1
	Viewing Angle	178° horizontal / 178° vertical
	Display Area	1549.44*871.56mm
	Video Interface	VGA HDMI
	Audio Interface	AUDIO IN
	Brightness Control	Automatically light sensor
Embedded PC	CPU	Intel ATOM D525 Dual Core 1.8G
	Memory	2 GB DDR2 800 MHz
	Display Card	NVIDIA GT218 512M Independent Video Memory
	Hard Disk	250 GB
	Interface	12V DC-in, Mic/Audio In, USB 2.0 Port(4), HDMI Port, VGA Conector 10/100/1000 Adaptive Ethernet
	Operation System	Windows 7
Operation	Operating Temperature	-40°C to +55°C
	Operating Humidity	5% to100%
	Protection Rating	IP65
	Power	AC 108-115V,50/60Hz
	Power	AC 208-240 V, 50/60 Hz
	Power Consumption	1.3 kW (Mainly for AC starting)
All in One Unit	Dimension (WxHxD)	2100 mm x 840 mm x 320 mm (Exclude back haging)
	Packing Size	2300mm* 950mm*450mm
	Weight	164kg
	Glass	6mm High light transmission, anti-reflective, tempered, safe glass
	Air Conditioning	Cooling and Heater all in one

Optional Configuration

-Touch Function	Infrared Touch or Capacitive Touch
-Wireless Networks/WIFI	External Wireless Network Interface connecting to PC
-Remote Info Issue & Management System	Integrated Networks remotely issue contents to display terminal and manage the contents of the display terminal as well
-Remote Environment Monitoring System	Integrated Networks available for remotely monitoring the inner operating status in the machine
-Anti Graffiti Protection	Special coating allows easy removal of graffiti without damaging surface
