Specifications
Sale Gabion1. ISO9001,CE,SGS test
2. Used exclusively for export
3. Competitive price
4. Fast delivery & High quality
1. Introduction
Sale Gabion
Gabion offers good ventilation and fencing uses. It is made of twisted carbon steel wire, electro or hot dipped galvanized, then plastic coated, or plain. It can be fabricated into gabions boxes – one of the most popular wire products for flood control. Then stones are put into them. Laying of gabions makes up a wall or bank against water and flood. Gabion can also be welded into poultry netting for breeding of chicken and other poultry. It is popularly used as fences after green coated, and costs can be reduced. In the past years, gabion is made of galvanized iron wire that has been used in fences, breeding and construction reinforcement.
Gabion wire mesh surface treatment is
a. Electro galvanized zinc coating:10g/m2
b. Hot dipped galvanized zinc coating:30-50g/m2
c. Heavy zinc coated:250-300g/m2
d. PVC coated, as usual. PVC thickness is 1mm
2. Applications
A1. Control and guide the water or flood
A2. Prevent the rock from breaking
A3. Protect the stone from falling
A4. Water and soil protection
A5. Bridge protection
A6. Strengthen the structure of soil
A7. Protect the engineering in seaside area
A8. Port projects
A9. Keep off dust wall
A10. Roadway protection
3. Characteristics
C1. Economcal. It only needs to load a stone cage that can be sealed.
C2. Simple construction. Special skills is hardly needed.
C3. A strong withstand natural damage and adverse influence of climate. It can also resist errosion.
C4. Be able to stand large-scale deformation, and will not collapse.
C5. Cage rock crevice between the mud can be used to plant production which enables the surrounding natural environment melt together.
C6. Has good permeability to prevent static fluid from causing damage.
C7. Save transportation costs. Can be folded up and assembled on site.
4. Specifications
Mesh Size |
No. Of Diaphragm |
Approximate Dimensions and Volumes |
Tolerance
|
Wire
|
|||
Length |
Width |
Depth |
Capacity |
||||
|
60x80 80x100 80x120 90x110 100x120 110x130 120x150
According to your requests. |
1 |
2.0m |
1.0m |
0.5m |
1.0m |
±5% |
Heavily galvanized, PVC Coated, Galfan coated.
Wire Diameter: 2.0, 2.2, 2.4, 2.7, 3.0, 3.5, 4.0mm
|
1 |
2.0m |
1.0m |
1.0m |
2.0m |
|||
2 |
3.0m |
1.0m |
0.5m |
1.5m |
|||
2 |
3.0m |
1.0m |
1.0m |
3.0m |
|||
3 |
4.0m |
1.0m |
0.5m |
2.0m |
|||
3 |
4.0m |
1.0m |
1.0m |
4.0m |
|||
1 |
2.0m |
0.5m |
0.5m |
0.5m |
|||
2 |
3.0m |
0.5m |
0.5m |
0.75m |
|||
4 |
5.0m |
1.0m |
0.5m |
2.5m |
|||
4 |
5.0m |
1.0m |
1.0m |
5.0m |
|||
5 |
6.0m |
1.0m |
1.0m |
6.0m |
|||
5. Packing and loading
6. Our services
S1. We can offer any sizes of gabion mesh, baskets or boxes according to the requirements of customers.
S2. We will reply you as soon as possible upon receving your request of your products.
S3. We can provide you with samples free of charge.
7. Company information
Konson Industrial Company Limited, with more than 15 years production experience, becomes one of the leading manufacturers of the gabions, mattress and gabion production line in China. We would like to offer good service and excellent products to customers wholeheartedly!
The company, with more than 100 experienced employees, has two workshops, one is for the gabion machine making, the other is for the gabion&mattress making. It has a production facility of more than 10 complete sets of gabion production line and four million square meters hexagonal wire mesh(gabion box) each year.
8. Customers and certificates
9. Related Photos
Workshop
