Specifications
Bronjong Kawat Gabion1. ISO9001:2008, UKAS
2. Material:Hot dip Galvanized Iron Wire
3. Mesh: 80x100mm
4. Prompt delivery
1. Introduction
Bronjong Kawat Gabion
Bronjong Kawat Gabions are made of double-twisted hexagonal wire mesh, it mainly can be produced with material like hot dipped galvanized steel wire, zinc and aluminum alloy coated steel wire, PVC coated steel wire, stainless steel wire, etc.
Bronjong Kawat Gabions are designed on the principle of a mass earth retaining wall. The strength and flexibility of the triple twisted mesh helps withstand and absorb the forces generated by retained earth or flowing water.
Bronjong Kawat Gabion is an economic material which is simple installation, good corrosion resistant, no collapse even under big scope of deforming, mixed to form a integrity with the natural environment. It is also can be folded together easily for transportation and further installation.
Bronjong Kawat Gabion is mainly used for landslide preventing, engineering of seaside area protecting, water or flood controlling or guiding, strengthening structure of soil, landscaping and retaining walls, etc.
2. Specifications
Opening (mm) |
Wire Diameter(Metal Wire) (mm) |
Wire Diameter (PVC Coate)/ Inner/Outside(mm) |
Strands |
60X80 |
φ2.0-2.8 |
φ2.0/3.0-2.5/3.5 |
3 |
80X100 |
φ2.0-3.2 |
φ2.0/3.0-2.8/3.8 |
3 |
80X120 |
φ2.0-3.2 |
φ2.0/3.0-2.8/3.8 |
3 |
100X120 |
φ2.0-3.4 |
φ2.0/3.0-2.8/3.8 |
3 |
100X150 |
φ2.0-3.4 |
φ2.0/3.0-2.8/3.8 |
3 |
120X150 |
φ2.0-4.0 |
φ2.0/3.0-3.0/4.0 |
3 |
(Note: The production's material and size can be producted as the customoer's requirement.)
3. Applications
A1. Control and guide of water or flood
A2. Flood bank or guiding bank
A3. Prevention of rock breaking
A4. Water and soil protection
A5. Bridge protection
A6. Strengthening structure of soil
A7. Protection engineering of seaside area
A8. Seaport engineering
A9. Isolation walls
A10. Protection of road
4. Features
F1.Economical. You just need to put stones into the gabion and seal it.
F2.Simple installation. No special technology is needed.
F3.Good resistance. Weather proof under natural destroy, corrosion resistance.
F4.Ecofriendly.Sludge in the stones is good for plant growing. Mixed to form a integrity with the natural environment.
F5.Good permeation. Can prevent the damage by hydrostatic.
F6.Less transportation freight. It can be folded together for transportation and further installation.
F7.High rigidity. No collapse even under big scope of deforming.
5. Project Photos
