Samsung Lcd Video Wall For Advertising Display
Panel Specifications | |
LCD Technology |
Samsung a-Si TFT-LCD |
Active Screen Diagonal |
55" (1397mm) |
Pixel Pitch(WxH) |
0.630x0.630mm |
Active Display Area(WxH) |
1209.6x680.4mm |
Panel Dimension(WxHxD) |
1215.3x686.1x64mm |
Total Bezel Width |
5.3mm | 0.208” |
Aspect Ratio |
16:9 |
Physical Resolution |
1920x1080 |
Backight System |
WLED |
Luminance(nits) |
450cd/sqm |
Contrast |
3500:1 (typ.) |
Viewing Angle |
H 178°|V 178° |
Display Colors |
8Bit,16.7M |
Refresh Rate |
60Hz |
Response Time |
<=6ms |
Life(hrs) |
>60,000(hrs) |
MTBF |
> 100,000h |
Surface |
Anti-glare |
Standby Power Consumption |
<3W |
Maximum Power Consumption |
<=250W |
Power Supply |
AC100~240V 50/60 HZ |
Cooling |
Low noise fans |
Heat Dissipation |
819 BTU/h (max) |
Working Time Capacity |
7x24x365hours |
Application Area |
Indoor/Semi Outdoor/Outdoor |
Working Temperature |
0°C~50°C |
Working Humidity |
85% non-condensing |
Storage Temperature |
-20-60°C | -4-149°F |
Storage Humidity |
85% non-condensing |
Processor | |
DVI-I DUAL LINK |
1 |
HDMI |
1 |
VGA |
1 |
CVBS IN |
1 |
CVBS OUT |
1 |
RS232 IN |
1 |
RS232 OUT |
2 |
ISP IN |
1 |
IR IN |
1 |
CODING BUTTON |
1 |
AC IN |
AC100-240V |
Color System Support |
PAL/NTSC/SECAM |
Control Type |
IR Remote &Software Control |
Menu Language |
English/Chinese(Multiple Language can be customized) |
Main Function:
1. |
Play mp4 movie, mp3 music and digital photos; Built-in 55 inch TFT LED screen, with tempered glass protection; easy-to-install on supermarket shelves. |
2. |
--Built-in pc |
3. |
Upgrade contents of Built-in memory by remote internet PC control |
4. |
Timer function: the player powers on / off automatically everyday at the time pre-set; It can also automatically play and non-stop replay within the pre-set time frame |
5. |
No DVD style mechanical movement, hence more durable and suitable for long-hour advertising playing |
6. |
IR (infrared) motion sensor: player starts automatically when the sensor detects an approaching viewer |
7. |
Audio output: 2 built-in high quality stereo speakers |
8. |
With professional easy-to-use stand set; |
9. |
LED ratio adjustable: 16 : 9 |
Video/ Picture / Audio Format: ( support HD 1080P video
Picture formats: BMP/JPEG/GIF/PNG Audio formats: MP3/M4A/AAC/WMA/ASF
Video formats: DAT/MPG/MPEG/TS/TRP/TP/M2TS/VOB/MP4/RM/RMVB/MKV/DIVX /AVI/MOTION JPEG/ASF/WMV
Language Support: Multi-language function: Chinese, English, France, Spanish, Korea etc
Others:
Casing material: Matel Power supply: AC100V~240V, 135W
Installation: shelf/wall-mounted or to be installed on desktop
Working temperature: -20°C - 40°C Working humidity: 10%-90%
Storage temperature: -40°C - 85°C Storage humidity: 10%-95%
Packing: Standard Exporting FengWo package 1 piece/package EPE foam inside
Application Area:
Public Places: bus, subway, airports, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers;
Business Organizations: supermarket, large-scale shopping malls, exclusive agency, chain shops, star-rated hotels, restaurants, travel agencies, pharmacy;
Financial Organizations: banks, negotiable securities, funds, insurance companies, pawnshops
Non-profit Organizations: telecommunications, post offices, hospital, schools;
Real Estate Property: apartments, villas, offices, commercial buildings, model rooms, property brokers;
Entertainments: movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, internet bars, beauty shops, golf course
