3W - 18W Ceiling Thin Lamp Bright White Warm Light 85-265V Panel Led Downlight

3W - 18W Ceiling Thin Lamp Bright White Warm Light 85-265V Panel Led Downlight thumbnail-1
3W - 18W Ceiling Thin Lamp Bright White Warm Light 85-265V Panel Led Downlight photo-1
US$ 2 - 15 MOQ: 100 Pieces
Key Specifications
Get Latest Price
LED Light Source:
led smd 2835
Warranty(Years):
2
Input Voltage(V):
AC110-265V
Contact Supplier Request Quote Chat Now
Hangzhou Elight Optoelectronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source led smd 2835
Warranty(Years) 2
Input Voltage(V) AC110-265V
Lamp Power(W) 12
Lamp Luminous Flux(lm) 21-23lm per led
Lamp Luminous Efficiency(lm/w) 90
Color Temperature(CCT) Other, warm white/pure white/cool white
Working Temperature(℃) -20, +50
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum
IP Rating Other, IP30, IP30
Certification CE
Model Number HE-P-6W
Place of Origin Zhejiang, China
Brand Name Elight

Specifications

Panel led downlight
1.Factory directly
2.Embedded or ceiling mounted
3.CE&ROHS



Product Description

Panel led downlight features:


-Use 2835SMD LED
-Efficient housing design results in 93% light utilisation
-Aluminum base design, heat dissipation excellent
-50, 000 hours average LED life span
-High Power Factor
-95% efficient integrated LED driver
-Warm white,natural white,cool white colour temperatures, CRI > 80
-Direct Use in AC110-265V



Panel led downlight specification:

Power Surface diameter Hole Size

Specification
3W 85mm 70mm

Round panel



Material: Aluminium +  frosted PMMA cover



SMD2835,Per LED21-23lm,Isolated IC Power Driver,Voltage:85-265V 50/60Hz,current output:240-260mA
6W 120mm 105mm
9W 145mm 130mm
12W 170mm 155mm
15W 190mm 175mm
18W 225mm 200mm
6W 120*120mm 110*110mm

Square panel



Material: Aluminium +  frosted PMMA cover



SMD2835,Per LED21-23lm,Isolated IC Power Driver,Voltage:85-265V 50/60Hz,current output:240-260mA
9W 145*145mm 130*130mm
12W 170*170mm 155*155mm
15W 190*190mm 175*175mm
18W 225*225mm 200*200mm



Panel led downlight pics



3W - 18W Ceiling Thin Lamp Bright White Warm Light 85-265V Panel Led Downlight



3W - 18W Ceiling Thin Lamp Bright White Warm Light 85-265V Panel Led Downlight



3W - 18W Ceiling Thin Lamp Bright White Warm Light 85-265V Panel Led Downlight    3W - 18W Ceiling Thin Lamp Bright White Warm Light 85-265V Panel Led Downlight



High quality light guide plate make the light uniform
PMMA diffuser has the light transmission rate up to 93%



3W - 18W Ceiling Thin Lamp Bright White Warm Light 85-265V Panel Led Downlight



Panel led downlight application

 3W - 18W Ceiling Thin Lamp Bright White Warm Light 85-265V Panel Led Downlight



Packaging & Shipping

  Package

  1.Each in a bubble bag/Foam inner package, then in a regular box

  2.Custom package is welcome



3W - 18W Ceiling Thin Lamp Bright White Warm Light 85-265V Panel Led Downlight



Company Information



We are a  professional led factory with 15 years manufacture experiences,products have been exported to Europe, Australia , Middle East, South America,etc.Our products are popular in wholesaler and projects.



Contact Us

If you are interested in our led panel light,please email us or call us 86-13157136332! Thank you!



Contact Person:Darcy

Email:marketing3(at)

Skype:darcylovely



Send Inquiry to This Supplier

Message
0/5000

Want the best price? Post an RFQ now!
Hangzhou Elight Optoelectronic Co., Ltd.
Business Type
Manufacturer, Trading Company
Year Established
2013
Factory Size
1,000-3,000 square meters
Total Employees
101 - 200 People
