Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine

Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine photo-1
US$ 5,000 - 6,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Loom Accessory Equipment
Application:
Tail Yarn Tube Cutting Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, Loom Accessory Equipment
Application Tail Yarn Tube Cutting Machine
Production Capacity 20-35 Pcs/Min
Place of Origin Zhejiang, China
Brand Name Hongyu
Model Number HY-300
Dimension(L*W*H) 2100*550*1600mm
Weight 260KG
Power(W) 4.5KW
Certification CE ISO9001
Warranty 1Year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine
Competitive Price
Quality sales service
Low Cost
Video .

Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine





Buyer Reading:

        Thanks for noting this , In order you to find the ideal machinery , Please tell us the bag you want to make ,or the material you will use when you send us the quotation.This can save you a lot of time ,kindly understand it.



Usage:

        Hy-300 circular loom cop tube& yarn waste automatic processor,replace manual work like using knife or electrical hot wire to process cop tube with tail yarn, automatically cut the tail on the yarn tube. this machine have a steady and reasonable structure,easy to operate ,and when it cut the tail yarn , it will not damage the yarn tube. just put the unfinished yarn tube into the entrance can make tail yarn be automatic cut and separate with yarn tube , meanwhile it can find available yarn spindle , prevent waste.



        This machine can save time and power , several circular loom product line just need one can finish the work that need several labor before, solve the problem of artificial waste &employment difficult. And at the same time it’s avoid the worker be cut or scald by using knife & heater.



        This machine has independent intellectual property rights.



Main technical parameters:



Model HY-300
The inner diameter of yarn tube φ31-38mm
The Max. thickness of tail line can cut ≤3mm
Cutting speed 20-30PC/min
Main motor power 0.75KW
Total Wattage 4.5KW
Weight 260kg
Size 2100mm×550 mm×1600mm



Tube With Tail Yarn

Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine



Put Tail Yarn Into Machine Entrance

Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine



Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine



Send Tubes To Blade(Cutter)

Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine



Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine



Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine



Tubes Finished Cutting(Tubes Finished Sperate With Tail Yarn)

Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine



Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine



Control And Counter Device

Tail Yarn Bobbin Cutting Machine Match For Circular Weaving Machine
