resin frame acoustic material fabric ceiling acoustic panel strong decorative

Specifications

acoustic material
1.Material:fiber glass
2.Size:600x600x25mm
3.NRC:0.83-0.95
4.CE,BV,ISO9001,SGS

 acoustic material

Made of special woven fabric, which is good for sound absorption, to pack the density of96kg/m3  Owens Corning fiberglass. Also can do fireproof treatment if customer needed.



Features of acoustic material



1)  Fabric acoustic wall panel is a acoustic material, using flame retardant resin border placed fireproof Class A specially designed non-combustible sound-absorbing cotton;



2) Made of outsourcing fireproof treatment flame-retardant B1 level acoustic fabric or leather, which is characterized by available for a variety of colors and patterns to choose from;



3) The finishes cloth material can be adjusted according to the requirements of the acoustic renovation or investors;



4) Fabric acoustic wall panels sound absorption spectrum is high, which have fairly good results for low, medium and high frequency noises, and good fire-proof, no dust pollution, strong decorative and simple to use.



5) Our common fabric acoustic wall panels include angle, rounded, beveled and other models. And there are many specification levels available for investors to choose, you can simply note when installing. Now we will provide installation method for centralized fabric acoustic panels for you.

1. Parameters



2. Edge cutting

3. Color chart

There are five series of  fabric acoustic wall panel available now, with different textures,touched with colors. Here are part of our color chart for your choice.

4.   acoustic material installation method.

Commonly used installation method of the fabric acoustic wall panel

After proper installation, the sound absorption effect of fabric acoustic wall panel is considerable. The commonly used installation method of the fabric acoustic wall panel is generally available for three kinds.



1) Firstly, flat placing installation. You can choose the "people" shaped aluminum dragon skeleton support, after fix the keel, compose a keel skeleton, then place the board flat on the limb of the keel, supporting through keel extremities, such structure is simple, easy to install; 2) Secondly, dark keel ceiling installation method, hang the keel flat, slot around the fabric acoustic panels, plug the keel limb into the dark slot after accommodation, rely on limbs to bear board;

3) The third method is to paste, the paste method has composite flat and composite insert paste method, the two fabric acoustic board paste method each have their own advantages, you can select according to the different actual situation.







  5. Sound absorption coefficient  and acoustic performance of acoustic material.



Reverberation time is the primary descriptor of an acoustic environment. A space with a long reverberation time is referred to as a "live" environment. When sound dies out quickly within a space it is referred to as being an acoustically "dead" environment. An optimum reverberation time depends highly on the use of the space. For example, speech is best understood within a "dead" environment. Music can be enhanced within a "live" environment as the notes blend together. Different styles of music will also require different reverberation times.





Reverberation time is affected by the size of the space and the amount of reflective or absorptive surfaces within the space. A space with highly absorptive surfaces will absorb the sound and stop it from reflecting back into the space. This would yield a space with a short reverberation time. Reflective surfaces will reflect sound and will increase the reverberation time within a space. In general, larger spaces have longer reverberation times than smaller spaces. Therefore, a large space will require more absorption to achieve the same reverberation time as a smaller space.

6. Thanks to its excellent physical property, fabric acoustic wall panel has no risk of falling and hurting people. Tested by National Research Center of Testing Techniques for Building Materials, the fabric acoustic wall panel formaldehyde release quantity is 0.1 and complies with the E1 grade requirements of GB18580-2001 standard.

      CE, ISO9001-2008, Alibaba supplier assessment report.

7. Applications of acoustic material.



Fabric acoustic wall panel are not only suitable for KTV decoration, it can also be used in a variety of high, intermediate decorated houses which need to do the sound quality design, such as theater, studio, dance hall, language lab, etc. As long as play properly good function of the fabric sound-absorbing panels, it can be applied to almost any place. Experts remind that there are many manufacturers offering fabric acoustic wall panels on the market, due to the impact of market competition intensifies and prices soaring, some fabric acoustic wall panel manufacturers cut corners, muddle the clearance to ensure that their own interests for the pursuit of low-cost, high-return, so at the time of purchase, we must pay attention to the quality of the fabric acoustic wall panel, purchase from the regular factory as far as possible.
