Help CenterOrange Color 1.5m UTP Cat5e RJ45 Networking Patch Cable
Related Products
-
Outdoor FTP Cat5e RJ45 to RJ45 Ethernet Lan CableUS$ 0.6 - 0.8MOQ: 1000 Pieces -
Competitive Factory Price Twisted Pair 4 Pair Cable RJ45 Cat5e CableUS$ 0.5 - 0.9MOQ: 100 Pieces
-
Cat6 Patch Cable RJ45US$ 0.6 - 0.7MOQ: 300 Rolls
-
Low Price FTP Network D-Link Cat 6 CableUS$ 0.35 - 0.6MOQ: 1000 Pieces
-
Hot Sell FTP Cat 6 Cables Network CableUS$ 0.35 - 0.6MOQ: 1000 Pieces
Specifications
1.Cat5e networking patch cable2. UTP 24AWG*4P,Copper&CCS
3.RJ45,8P8C.
4. PVC molding with boot
5.CE&UL&RoHS
Orange color 1.5m UTP Cat5e RJ45 networking patch cable with boot
Specification:
1.CAT5E UTP and FTP Patch cable
2.with RJ45 8P8C connector
3.Rated Temperature:75Degree
4. Solid/Strands Cores are available
5. Standard:UL444,TIA/EIA568B.2,YD/T1019-2001
6. 24AWG*4P, 23AWG*4P, OD:5.5mm-6.0mm
7. Insulation :HDPE,
8. Jacket: PVC
9. Rip cord: Per your request
Features and benefits
1. 6-50 micron RJ-45 staggered gold plated connectors .
2. Fitted with strain relief boots
3. With or without reports made to the order
4. 100% tested wiring sequence and continuity
5. Excellent attenuation and crosstalk characteristics
6. With or without reports made to the order
7. Connector with staggered pin configuration to limit cross talk .
8. Exceed Category 5E requirement .
9. They are available in a variety of the lengths
Products Description:
Constructed of High-Performance Cat 5E cable suitable for 1000MHZ High-speed data applications, gigabit ethernet, fast ethernet, 155Mbps TP-PMD/CDDI . Boots offer cable-end color ID, strain relief and RJ45 plug tab protection from snagging on cables or connectors when routing in ceiling and under floors, suitable for indoor installations.
Electrical Characteristic:
1.1.0-100.0MHz Impedance (ohms):100 +/- 15
2.1.0-350.0MHz Delay Skew (ns/100m):<=45
3.Pair-to-Ground Capacitance Unbalance (pF/100m):<=330
4.Max. Conductor DC Resistance 20 degree(ohms/km):93.8
5.Resistance Unbalance (%):<=5
Application: 100 Base-TX, 100VG-AnyLAN, 1000Base-T, ATM, Noisy Environment
Remark: 250MHz 550MHz ATM 155Mbps, 100mbps TPDDI, Fast Ether-net etc.
