Help CenterRoHS Compliant & UL Wire 68 Pin SCSI Connector Cable
Related Products
-
Top Standard 68P SCSI to VHDCI 68 Pin CableNegotiableMOQ: 1000 Pieces -
D-sub 25 Pins to Scsi 26 Pins CableNegotiableMOQ: 1000 Pairs
-
New 6ft DB50 SCSI Cable M/MNegotiableMOQ: 1000 Pieces
-
UL Certificated SCSI HPCN 50Pin Assembly CableUS$ 2.3 - 37MOQ: 1000 Pieces
-
Top Standard SCSI HPDB 68P to VHDCI 68 Pin CableNegotiableMOQ: 1000 Pieces
Specifications
1.68 Pin SCSI connector cable2.UL wire,RoHS compliant for all materials
3.7 yrs factory
4.tinned 28awg conductor
VHDCI(The Very High Density Cable Interconnect) is a 68-pin connector that was introduced in the SPI-3 document of SCSI-3. The VHDCI connector is a very small connector that allows placement of four wide SCSI connectors on the back of a single PCI card slot. Physically, it looks like a miniature Centronics type connector. It uses the regular 68-contact pin assignment.
VHDCI cables have also been used by NVidia as an external PCI Express 8-lane interconnect, and used in Quadro Plex VCS.
ATI Technologies is now using VHDCI connectors on the FireMV 2400 to convey two DVI and two VGA signals on a single connector, and ganging two of these connectors side-by-side in order to allow the FireMV 2400 to be a low-profile quad display card.
Juniper Networks uses VHDCI connectors for their 48-port 100Base-TX PIC (Physical Interface Card). The cable used to connect to the VHDCI connector on the PIC on one end, connects via an RJ-21 connector on the other end, to an RJ-45 patch panel.
Electrical Test
1. Hi-Pot Test: DC300V.
2. Insulation Resistance: 5M Ohms (Min).
3. Contactor Resistance: 2 Ohms (Max).
4. 100% Open Short and Miss Wire Test.
