Full HD VGA to BNC Cable for Computer
VGA to BNC Cable Specifications:
Application |
Surveillance camera,Sectunity monitor,CCTV camera etc |
Connector type |
VGA to BNC |
Color |
Black |
Length |
3ft/6ft(optional) |
OD |
5.5MM |
Numble of core |
16 |
Conductor material |
99.96% Pure Copper |
Conductor gauge |
9/0.12 |
Drain wire |
20/0.1 |
Insulation material |
PE |
Jacket material |
PVC |
Connector material |
Zinc Alloy |
Ferrite |
No |
Line card identification |
Yes |
Logo |
Customized |
F VGA to BNC Cable eatures:
- Specification: 28AWG+D.W+AL/myx3C+28AWGx8C+AL+DRAIN(28AWG)+BRAID+PVC jacket, OD:5.5mm+_0.2mm
- Connector: P1, P2: HDB 15pin male gold flash contact, nickel or golden plated shell optional.
- Shield: P1&P2 copper foil 360° soldered to connector.
- Accommodates cable runs to 100 feet without a booster(in most cases)
- Ideal for video presentation devices, video splitters, and KVM switches.
Electrical:
100% open & short test
Hi-Pot: DC 300V 10ms
Insulation Resistance: 20M OHM /300V Min.
Shield up to 65% braid.
Working Temperature: -20oC ~ +85oC
Mechanical
Over mold: PVC UL94V-0 Blue or customized
Pre mold: PE Low Density
Contact: Copper Alloy
VGA to BNC Cable
