Product name:
HD SDI Cable with Right Angled MCX Connector For CCTV Security Camera
Specifications:
Connector Type: |
HD SDI Cable |
Shielding: |
Combination |
Gender: |
Female-Male |
Lebgth: |
0.3M-10M |
Connector material: |
Zinc alloy |
Number of core: |
8 |
Conductor material: |
Bare copper |
Conductor gauge: |
9/0.12 |
Drain wire gauge: |
20/0.1 |
Insulation material: |
PE |
Jacket material: |
PVC |
Color: |
Blake,whte,yellow and else |
Coaxial cable Certification |
UL & ROHS compliant |
Features and Application:
Surveillance camera, Security monitor, CCTV camera, LCD,HDTV etc
1. HD SDI Cable with Right angled MCX connector For CCTV nickel plated connectors, PVC molded type LCD monitor video cable
2.RGB, vertical sync, horizontal sync
3.Transmits Analog signals only
4.Used to connect to displays which utilize 18-way BNC connections.
6.monitor video cable used for
7.High quality double shielded BNC to SVGA cables to attach your monitor.
8.This HD SDI Cable For CCTV connects PC or laptop to the projector, LCD monitor, and other video display system through HD SDI connectors.
9.Constructed from premium grade shielded video monitor cable which used a combination of coax and twisted pair
10. HD SDI Cable for CCTV
Packaging Detail:
normal package: PE BAG,125pcs in a carton.
1.plastic package can be designed.
2.inner packing : PE bag/blister or as customers' requirement
3.outside packing :46*30*23cm
Shipping and delivery details:
1)if quantity is not very big ,Most of the items will be sent within 1-3 days after payment is confirmed. It usually takes around 3-5 workings to air ship to your countries by express ,such as DHL,EMS,TNT,UPS OR FEDEX . (Please kindly get that we are not responsible for any accidence, delays ,and other issures caused by shipping company .)
2) Items will be 100% checked by our Electrical testing & professional inspector before shipping
Electrical Testing:
2.1 100% open and short test;
2.2 Voltage: DC300V 5M ohm/10ms;
2.3 Insulation Resistance: 10MO min;
2.4 Contact Resistance: 2ohm max
2.5 Working Temperature:-25°C--80°C
After-sales service:
1).Our slogan is "keeping in touch with our customers with parts of quality and benefiting our customers with best service.
2).Our promise, so long as product quality has question, upon test and find out if they are our fault, we can exchange or resupply to you for free with my company connection.
